Uvod
This manual provides essential instructions for the safe and efficient use of your ANCHEER 48V-7.8Ah Battery, Model AMAK00012. Please read this manual thoroughly before installation, operation, or maintenance to ensure proper function and prolong the lifespan of your battery. Retain this manual for future reference.
Image: The ANCHEER 48V-7.8Ah Battery, showcasing its rectangular form factor, integrated handle, and key-operated power switch.
Sigurnosne informacije
Your safety is paramount. Observe the following precautions:
- Do not disassemble, modify, or attempt to repair the battery. This can lead to electric shock, fire, or explosion.
- Keep the battery away from water, moisture, and extreme temperatures (both high and low).
- Use only the charger specified by ANCHEER for this battery. Using an incompatible charger can cause damage or fire.
- Izbjegavajte kratki spoj terminala baterije.
- Bateriju čuvajte na hladnom i suhom mjestu, dalje od direktne sunčeve svjetlosti i zapaljivih materijala.
- Čuvati van domašaja djece i kućnih ljubimaca.
- Ako baterija pokazuje znakove oštećenja, curenja ili pregrijavanja, odmah prekinite upotrebu i obratite se podršci.
- Odložite bateriju u skladu s lokalnim propisima za litijum-jonske baterije. Ne bacajte je u kućni otpad.
Sadržaj paketa
Carefully unpack your ANCHEER 48V-7.8Ah Battery and check for any damage. The package should contain:
- ANCHEER 48V-7.8Ah Battery
Please note: A compatible charger and mounting keys are typically supplied with the electric bicycle or purchased separately. Verify your complete order for all necessary accessories.
Setup
1. Početna naplata
Before first use, fully charge the battery. Connect the charger to the battery's charging port, then plug the charger into a standard wall outlet. The charger indicator light will typically change from red to green when charging is complete. Disconnect the charger once fully charged.
2. Instalacija baterije
The ANCHEER 48V-7.8Ah Battery is designed for specific electric bicycle models, such as the one shown below. Ensure the battery mounting bracket on your e-bike is compatible.
- Align the battery with the mounting bracket on your e-bike frame.
- Slide the battery firmly into place until it clicks securely.
- Use the provided key to lock the battery to the frame. This prevents theft and ensures the battery remains secure during operation.
Image: An ANCHEER 48V-7.8Ah Battery securely mounted on the frame of an electric bicycle, demonstrating typical installation.
Operating
1. Uključivanje / isključivanje napajanja
To power on the battery, insert the key into the key slot and turn it to the 'ON' position. To power off, turn the key to the 'OFF' position. The key can also be used to unlock the battery from the bike frame.
Slika: Detaljna view of the ANCHEER battery's top panel, showing the power button, LED charge indicator, and the key ignition switch.
2. Indikator nivoa baterije
The battery features an LED indicator on its top surface to display the current charge level. Press the power button briefly to activate the indicator. The number of illuminated LEDs corresponds to the remaining charge:
- All LEDs lit: Puno punjenje
- Fewer LEDs lit: Dekretasing charge level
- Single LED blinking: Low charge, recharge immediately
3. Punjenje baterije
To charge the battery, ensure it is powered off. Connect the charger's output plug to the battery's charging port. Then, plug the charger's input cable into a suitable AC power outlet. Monitor the charger's indicator light for charging status. Always disconnect the charger once the battery is fully charged.
Održavanje
1. Čišćenje
Obrišite bateriju casing with a soft, dry cloth. Do not use abrasive cleaners, solvents, or immerse the battery in water. Ensure the charging port and terminals are clean and free of debris.
2. Skladištenje
If storing the battery for an extended period (more than one month), charge it to approximately 50-70% capacity. Store in a cool, dry place between 0°C and 20°C (32°F and 68°F). Avoid extreme temperatures. Recharge the battery every 2-3 months to prevent deep discharge, which can damage the battery.
3. Praksa naplate
- Izbjegavajte potpuno pražnjenje baterije prije ponovnog punjenja.
- Do not leave the battery on the charger indefinitely after it is fully charged.
- Punite bateriju u dobro provetrenom prostoru.
Rješavanje problema
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Baterija se ne uključuje | Battery is fully discharged; Key not in 'ON' position; Loose connection. | Charge the battery; Turn key to 'ON'; Ensure battery is securely mounted. |
| Baterija se ne puni | Charger not connected properly; Faulty charger or outlet; Battery too hot/cold. | Check all connections; Try a different outlet; Allow battery to reach room temperature. |
| Reduced range/capacity | Battery aging; Improper charging habits; Extreme operating temperatures. | Ensure proper charging and storage; Battery replacement may be necessary over time. |
If troubleshooting steps do not resolve the issue, please contact ANCHEER customer support.
Specifikacije
| Feature | Detalj |
|---|---|
| Brand | ANCHEER |
| Naziv modela | AMAK00012 (YF0111004_00039) |
| Voltage | 48V |
| Kapacitet | 7.8Ah |
| Broj modela stavke | YF0111004_00039 |
| ASIN | B0FPF2M4HS |
| Dimenzije paketa | 5 x 5 x 5 inča |
| Proizvođač | ANCHEER |
| Datum prve dostupnosti | 2. septembra 2025 |
Garancija i podrška
For warranty information, technical support, or service inquiries, please refer to the warranty card included with your original electric bicycle purchase or contact ANCHEER customer service directly. Please have your product model number (AMAK00012 or YF0111004_00039) and ASIN (B0FPF2M4HS) available when contacting support.
You can typically find support contact details on the official ANCHEER webweb-stranice ili putem vaše platforme za kupovinu.
