Cecotec Conga X50 robotski usisivač i krpa sa samopraznećom bazom - uputstvo za upotrebu

Uvod

This manual provides detailed instructions for the safe and efficient use of your Cecotec Conga X50 Robot Vacuum and Mop. Please read this manual thoroughly before operating the device and retain it for future reference.

The Cecotec Conga X50 is an advanced robotic cleaning system designed to vacuum and mop various floor types. It features laser navigation for precise mapping, powerful suction, rotating mops for effective scrubbing, and a 4-in-1 self-emptying base for autonomous maintenance.

Sadržaj paketa

Provjerite da li su sve komponente prisutne u paketu:

• Conga X50 Robot Vacuum and Mop
• Self-Emptying Base with 2 tanks (clean water and dirty water)
• Dust Bag (pre-installed or spare)
• Bočna četka
• 2 Rotating Mops
• Power Cable
• Četka za čišćenje
• Korisnički priručnik (ovaj dokument)

Image: The Cecotec Conga X50 robot vacuum and mop, its self-emptying base, and included accessories such as dust bags, side brush, and rotating mops.

Setup

1. Raspakivanje i postavljanje

1. Pažljivo izvadite sve komponente iz pakovanja.
2. Choose a suitable location for the self-emptying base. Ensure it is against a wall, with at least 1 meter (3 feet) of clear space on either side and 1.5 meters (5 feet) in front, free from obstacles.
3. Connect the power cable to the base and plug it into a power outlet.
4. Place the robot onto the charging contacts of the base to charge fully before first use.

Image: The self-emptying base connected to power, with the robot docked for charging. This illustrates the recommended placement for optimal operation.

2. Initial Robot Preparation

• Install the side brush by pressing it into its designated slot on the underside of the robot.
• Attach the rotating mops to the mop holders on the robot's underside. Ensure they are securely fastened.

Image: The underside of the Conga X50 robot, highlighting the main brush, side brush, and the two rotating mops in position.

3. App Connection (Bluetooth & WiFi)

1. Download the "Cecotec Conga" app from your smartphone's app store.
2. Kreirajte nalog ili se prijavite.
3. Follow the in-app instructions to add your Conga X50 robot. This typically involves enabling Bluetooth on your phone and connecting the robot to your home's 2.4 GHz WiFi network.

Image: A smartphone screen displaying the Cecotec Conga app interface, showing the robot's status and mapping features, indicating successful app connection.

Uputstvo za upotrebu

1. Prva upotreba i mapiranje

For the first cleaning cycle, allow the robot to complete a full cleaning run without interruption. This enables the laser navigation system to create an accurate map of your home.

Image: The Conga X50 robot using its laser navigation to map a room, showing a dog and a soccer ball as potential obstacles it detects.

2. Režimi čišćenja

The robot offers various cleaning modes accessible via the app:

• Automatski režim: Robot inteligentno čisti cijelo mapirano područje.
• Čišćenje na licu mjesta: Directs the robot to clean a specific small area intensively.
• čišćenje zona: Omogućava vam da definišete određene zone na mapi koje robot treba da čisti.
• Zabranjena područja: Set virtual walls or no-go zones on the map to prevent the robot from entering certain areas.

Image: A smartphone displaying the Conga app with a detailed floor plan, illustrating how users can plan and schedule cleaning routes for the robot.

3. Suction and Mopping

• The robot features 15000 Pa suction power for effective vacuuming.
• The rotating mops provide thorough scrubbing for hard floors.
• Detekcija tepiha: The robot automatically detects carpets and increases suction power while lifting the mops to prevent wetting the carpet.

Image: Close-up of the Conga X50's underside, showing the two rotating mops actively scrubbing the floor, with arrows indicating their rotational movement.

Image: The Conga X50 robot approaching a carpet, with an upward arrow indicating its mops are being lifted to avoid wetting the carpet while vacuuming.

Održavanje

1. Self-Emptying Base Maintenance

• vreća za prašinu: The base automatically empties the robot's dustbin into a disposable dust bag. Replace the dust bag when full.
• Spremnik čiste vode: Refill the clean water tank (4 L capacity) with fresh water as needed.
• Rezervoar za prljavu vodu: Empty and clean the dirty water tank (3.5 L capacity) regularly to prevent odors and germ buildup.
• The base also dries the mops to prevent odors.

Image: The self-emptying base of the Conga X50, showing the transparent clean water tank filled with blue water and the dirty water tank, indicating its autonomous maintenance capabilities.

2. Čišćenje komponenti robota

• Glavna četka: Regularly remove hair and debris from the main brush using the provided cleaning tool.
• bočna četka: Check for tangled hair or debris and clean as necessary. Replace if worn.
• Rotating Mops: Remove and wash the mops after each mopping cycle. Allow them to air dry completely before reattaching.
• Senzori: Wipe the robot's sensors (laser, cliff, and anti-collision) with a dry, soft cloth to ensure optimal navigation.
• HEPA filter: Tap out dust from the HEPA filter periodically. Replace the filter every 3-6 months, depending on usage.

Image: Close-up of the Conga X50's main brush, showing debris being collected, emphasizing the importance of regular cleaning for optimal performance.

Rješavanje problema

Specifikacije

Garancija i podrška

Za informacije o garanciji, molimo pogledajte garantni list koji dolazi uz vaš proizvod ili posjetite službenu Cecotec stranicu. website. For technical support, troubleshooting assistance, or to order replacement parts, please contact Cecotec customer service through their official channels.

Više informacija i kontakt podatke možete pronaći na Cecotec Official Store on Amazon.
