REOLINK RP-WCB8MZ 4K Wi-Fi 6 Vanjska sigurnosna kamera - Korisnički priručnik

1. Uvod

This manual provides comprehensive instructions for the installation, operation, and maintenance of your REOLINK RP-WCB8MZ 4K Wi-Fi 6 Outdoor Security Camera. Please read this manual thoroughly before using the product to ensure proper setup and functionality. Keep this manual for future reference.

2. Proizvod je gotovview

The REOLINK RP-WCB8MZ is a high-performance 4K outdoor security camera featuring Wi-Fi 6 connectivity, 5X optical zoom, and advanced AI detection capabilities. It is designed for reliable outdoor surveillance with IP67 waterproofing.

2.1 Komponente kamere

Familiarize yourself with the various parts of your security camera:

Opis slike: A detailed diagram illustrating the REOLINK RP-WCB8MZ camera and its various components. Labels point to the CDS Sensor, Infrared LED, Spotlight, Lens, Aperture Hood, Microphone, Speaker, Antenna, Mounting Bracket, microSD Card Cover, Alarm Input/Output, Power Port, Reset Button, and Network Port.

• CDS Sensor: Detects ambient light levels for automatic day/night mode switching.
• Infracrvena LED: Provides illumination for black and white night vision.
• Spotlight: Aktivira se za noćni vid u boji i odvraćanje.
• Objektiv: Snima video footage.
• Aperture Hood: Protects the lens and reduces glare.
• mikrofon: Snima zvuk za dvosmjernu komunikaciju i snimanje.
• govornik: Enables two-way audio and plays custom voice alerts.
• antena: Za Wi-Fi povezivanje.
• Montažni nosač: Used for secure installation on walls or ceilings.
• microSD Card Cover: Protects the microSD card slot.
• Ulaz/Izlaz alarma: For connecting external alarm devices.
• Napajanje: Povezuje se na strujni adapter.
• Dugme za resetiranje: Koristi se za vraćanje fabričkih postavki.
• Mrežni port: Za žičanu mrežnu vezu (opciono).

3. Ključne karakteristike

• 4K/8MP Resolution with 5X Optical Zoom: The camera delivers 4K (8-megapixel) video resolution, providing clear and detailed images. The 5X optical zoom allows for magnification of distant objects without loss of clarity.

Opis slike: A split image demonstrating the clarity of 4K/8MP resolution and the detail captured with 5X optical zoom. The top panel shows a wide street view in 4K, while the bottom panel shows a zoomed-in section of a storefront with 5X optical zoom, highlighting fine details.
• Noćni vid u boji: Equipped with spotlights, the camera can capture full-color video even in low-light conditions, enhancing visibility and detail at night.


Opis slike: A screenshot from the Reolink app showing a vivid color night vision view of an outdoor scene with people near a building. The image demonstrates the camera's ability to capture colors in dark environments.

• Pametno otkrivanje putem umjetne inteligencije: The camera can intelligently distinguish between humans, vehicles, and animals, reducing false alarms caused by irrelevant movements. It also supports package detection and detection of non-motorized objects.


Opis slike: An illustration showing the camera detecting a person, a vehicle, and an animal (dog) in an outdoor setting. Notification bubbles indicate instant alerts for each detected category, demonstrating the AI smart detection feature.

• Zaštita perimetra: Configure specific detection zones such as line crossing, zone intrusion, and zone loitering to monitor critical areas. Note: Perimeter settings are currently managed via the Reolink App.

Opis slike: A multi-panel image displaying different perimeter protection alerts within the Reolink app interface. It shows visual representations of Line-Crossing Alert, Zone Intrusion Alert, and Zone Loitering Alert, along with detection of forgotten objects and absence of objects.
• Local AI Video Search: Utilize descriptive keywords to quickly find specific event-based footage stored locally.


Opis slike: A depiction of the Reolink app's AI Video Search feature, where a user types 'Delivery man' to search for relevant footage. Multiple small video thumbnails are shown, illustrating the search results for various events involving people and packages.

• Dvopojasni Wi-Fi 6: Supports both 2.4GHz and 5GHz Wi-Fi bands, offering stable and fast wireless connectivity. 5GHz provides higher speeds in open areas, while 2.4GHz offers better penetration through walls.


Opis slike: A graphic illustrating the benefits of Wi-Fi 6 for the security camera, emphasizing Superfast Transfer, Low Latency, and Higher Stability. The image shows the camera with prominent Wi-Fi antennas and text explaining the advantages of 5GHz and 2.4GHz bands.

• Fleksibilne opcije snimanja: Supports recording to a microSD card (up to 512GB), a Reolink NVR (Network Video Recorder), or an FTP server for continuous 24/7 recording without subscription fees.

Opis slike: A visual representation of the camera's flexible recording options. It shows a microSD card slot supporting up to 512GB, an icon for 24/7 recording with a Reolink NVR, and an FTP folder icon, indicating various storage methods.
• Dvosmjerni zvuk: Ugrađeni mikrofon i zvučnik omogućavaju komunikaciju u realnom vremenu putem kamere.
• IP67 vodootporan: Designed to withstand outdoor weather conditions, ensuring durability and reliable operation.

4. Upute za postavljanje

4.1 Šta se nalazi u kutiji

Before starting the installation, ensure all components are present:

• REOLINK RP-WCB8MZ Camera Body
• Predložak za montažu
• Vijci za montažu i zidni tiplovi
• Adapter za napajanje
• Network Cable (for initial setup or wired connection, if applicable)
• Vodič za brzi početak

4.2 Početno podešavanje

1. Uključeno: Spojite kameru na adapter za napajanje i uključite je u električnu utičnicu. Kamera će se uključiti i pokrenuti sekvencu pokretanja.
2. Preuzmite aplikaciju Reolink: Download and install the official Reolink App from your smartphone's app store (iOS or Android).
3. Dodaj kameru: Open the Reolink App, tap the '+' icon to add a new device. Scan the QR code located on the camera body or packaging. Follow the on-screen instructions to connect the camera to your Wi-Fi network.
4. Create Password: Set a strong password for your camera for security purposes.
5. Uživo View: Nakon povezivanja, trebali biste biti u mogućnosti view the live feed from your camera within the app.

4.3 Fizička instalacija

The camera is designed for wall or ceiling mounting. Choose a location that provides the desired viewing angle and has a stable Wi-Fi signal.

1. Odaberite lokaciju: Identify a suitable outdoor location, ensuring it is within Wi-Fi range and has access to a power source.
2. Montaža: Use the provided mounting template to mark screw holes. Drill pilot holes, insert wall anchors if necessary, and secure the mounting bracket with screws.
3. Priloži kameru: Attach the camera body to the mounting bracket and adjust the angle for optimal coverage.
4. Upravljanje kablovima: Route the power cable and any other cables securely to protect them from weather and tampering.

Opis slike: A small image showing the REOLINK RP-WCB8MZ camera securely mounted on the exterior brick wall of a building, demonstrating a typical installation scenario.

5. Uputstvo za upotrebu

5.1 Daljinski upravljač Viewing

Pristupite prijenosu uživo i snimljenoj hrani vaše kameretage from anywhere using the Reolink App or client software on your computer.

• Open the Reolink App and select your camera from the device list.
• Uživo view will display automatically.
• Use the controls on the screen to zoom in/out (digital zoom), access playback, or adjust settings.

5.2 Dvosmjerni audio

Uključite se u razgovore u stvarnom vremenu putem kamere.

• Dok je u živo view, tap the microphone icon to speak.
• Tap the speaker icon to listen to audio from the camera's location.

5.3 Smart Detection & Alerts

Configure the camera to send notifications for specific events.

• Navigate to the camera settings in the Reolink App.
• Go to 'Detection Alarm' or 'Smart Detection' settings.
• Enable detection types (Human, Vehicle, Animal, Package, Non-motorized Object).
• Set up push notifications, email alerts, or siren/spotlight activation upon detection.
• For perimeter protection (line crossing, zone intrusion, zone loitering), configure these options within the Reolink App's detection settings.

5.4 Opcije snimanja

Manage how your camera records footage.

• MicroSD kartica: Insert a microSD card (up to 512GB) into the designated slot. The camera will automatically begin recording based on your settings (continuous or motion-triggered).
• Relink NVR: Connect the camera to a compatible Reolink NVR for centralized recording and management.
• FTP: Configure FTP settings in the camera's web interface or app to upload recordings to an FTP server.
• Pristup snimljen footage via the 'Playback' function in the Reolink App or client software.

6. Održavanje

Redovno održavanje osigurava optimalne performanse i dugotrajnost vaše sigurnosne kamere.

• Očistite sočivo: Periodically wipe the camera lens with a soft, damp cloth to remove dust, dirt, or water spots that may affect image quality.
• Provjerite veze: Ensure all cables (power, network) are securely connected and free from damage.
• Ažuriranja firmvera: Regularly check for and install firmware updates via the Reolink App or website to benefit from new features and security enhancements.
• Pregledajte montažu: Verify that the camera is still securely mounted and has not become loose due to weather or other factors.
• Zaštita od vremenskih prilika: While IP67 rated, extreme weather conditions (e.g., heavy snow, ice) may temporarily affect performance. Ensure no obstructions block the camera's view.

Opis slike: A small image depicting the REOLINK camera mounted outdoors during rainfall, illustrating its IP67 waterproof rating and ability to function in various weather conditions. A temperature bar indicates its operational range from -30°C to 55°C.

7. Otkrivanje problema

This section addresses common issues you might encounter with your REOLINK RP-WCB8MZ camera.

8. Specifikacije

Detailed technical specifications for the REOLINK RP-WCB8MZ camera:

9. Garancija i podrška

For warranty information, technical support, or further assistance, please visit the official REOLINK website or contact REOLINK customer service. Details can typically be found on the product packaging or the REOLINK support portal.

Online resources often include FAQs, video tutorials, and community forums to help you get the most out of your REOLINK product.
