1. Proizvod je gotovview
The AsperX 15000mAh Portable Charger Power Bank is designed to provide reliable and fast charging for a wide range of electronic devices. Featuring both USB-C input and output, along with traditional USB-A outputs, this power bank ensures broad compatibility and efficient power delivery. Its compact design makes it an ideal companion for travel and daily use.
Image: Two AsperX 15000mAh portable power banks, showcasing their sleek black design and compact form factor.
2. Sadržaj paketa
Molimo Vas da provjerite da li se u Vašem paketu nalaze svi artikli:
- 2 x AsperX 15000mAh Portable Chargers
- 2 x USB kabel za punjenje
- 1 x Uputstvo za upotrebu
Image: A visual representation of the items included in the AsperX 15000mAh portable charger package.
3. Postavljanje i početna upotreba
3.1 Punjenje Power Bank-a
Before first use, it is recommended to fully charge your AsperX power bank. Use the provided USB cable and connect it to a compatible USB wall adapter (not included). The LED indicator lights on the power bank will show the charging status.
- Spojite USB-C ili Micro USB ulazni priključak power bank-a na izvor napajanja.
- LED indikatori će se upaliti kako bi prikazali napredak punjenja.
- Once all LED indicators are solid, the power bank is fully charged.
Važna napomena:
- Please use an adapter or charging cable with a power rating lower than 5V x 3A to charge the battery pack.
- Do not charge the power bank via a computer's USB port, as it may not provide sufficient power.
Image: Illustration of the USB-C input and output capabilities of the power bank, highlighting its versatility.
4. Uputstvo za upotrebu
4.1 Punjenje vaših uređaja
The AsperX power bank can charge multiple devices simultaneously using its USB-A and USB-C output ports.
- Spojite kabel za punjenje vašeg uređaja na jedan od izlaznih priključaka power bank-a (USB-A ili USB-C).
- Priključite drugi kraj kabla u uređaj.
- Power bank će automatski početi puniti vaš uređaj.
- LED indikatori će prikazivati preostali nivo napunjenosti baterije power bank-a.
Image: The power bank actively charging three different devices at once, demonstrating its multi-device charging capability.
4.2 Mogućnost brzog punjenja
This power bank supports 3A high-speed charging, significantly reducing charging times for compatible devices. The USB-C port functions as both input and output, offering versatile charging options.
Image: A visual comparison illustrating the faster charging speed of the AsperX power bank compared to standard chargers.
4.3 Kompatibilnost
The AsperX power bank is designed for wide compatibility, supporting not only smartphones and tablets but also low-power devices such as AirPods, Bluetooth headphones, fitness trackers, and smartwatches.
Image: A comprehensive chart detailing the broad compatibility of the power bank with various mobile devices and accessories.
4.4 LED indikatorska svjetla
The power bank features LED indicator lights to display the current battery level. Each light typically represents a percentage of the total capacity, allowing you to easily monitor the remaining power.
- 4 LED diode: 75-100% naplaćeno
- 3 LED diode: 50-75% naplaćeno
- 2 LED diode: 25-50% naplaćeno
- 1 LED: Napunjeno 0-25% (uskoro dopuna)
5. Održavanje i sigurnost
5.1 Opšta njega
- Držite power bank dalje od ekstremnih temperatura, direktne sunčeve svjetlosti i vlažnog okruženja.
- Očistite power bank mekom, suhom krpom. Ne koristite jake hemikalije ili abrazivne materijale.
- Power bank čuvajte na hladnom i suhom mjestu kada ga ne koristite duži period.
5.2 Sigurnosne mjere
- Do not disassemble, modify, or repair the power bank yourself.
- Izbjegavajte ispuštanje, udaranje ili izlaganje power bank-a jakim potresima.
- Čuvati van domašaja djece.
- Do not use this product while charging the power bank itself.
- Odložite power bank odgovorno u skladu s lokalnim propisima.
Image: A graphic representing the multi-protect safety system integrated into the AsperX power bank, ensuring device and user safety.
6. Otkrivanje problema
If you encounter issues with your AsperX power bank, please refer to the following common problems and solutions:
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Power bank se ne puni | Problem sa kablom, problem sa adapterom, power bank je potpuno napunjen. | Try a different USB cable or wall adapter. Ensure the adapter meets the power bank's charging requirements. Check LED indicators. |
| Uređaj se ne puni iz power banke | Power bank low on battery, cable issue, device compatibility. | Recharge the power bank. Try a different charging cable. Ensure your device is compatible and the cable is properly connected. |
| Sporo punjenje | Cable quality, device input limit, multiple devices charging. | Use a high-quality charging cable. Ensure your device supports fast charging. Disconnect other devices if charging multiple simultaneously. |
| LED indikatori ne rade | Power bank completely drained, internal fault. | Attempt to charge the power bank for an extended period. If the issue persists, contact customer support. |
7. Specifikacije
| Feature | Detalj |
|---|---|
| Broj modela | AX1515 |
| Kapacitet baterije | 15000mAh |
| Ulazni portovi | USB-C (5V/3A), Micro USB (5V/2A) |
| Izlazni portovi | USB-C (5V/3A), USB-A x 2 (5V/3A) |
| Posebne karakteristike | Fast Charging, LED Indicator Lights, Pocket Size, Slim Design |
| Dimenzije proizvoda | 15 x 1.2 x 7 cm |
| Težina artikla | 700 g |
| Vrsta baterije | Lithium Ion |
Image: A size comparison of the AsperX power bank with an iPhone 14 Pro, illustrating its compact and portable dimensions.
8. Garancija i podrška
AsperX offers an industry-leading 24-mjesečna garancija for this product. This warranty covers manufacturing defects and ensures reliable performance.
If you have any questions, require technical assistance, or need to claim warranty service, please do not hesitate to contact our customer support team. Refer to the contact information provided in your product packaging or visit the official AsperX webstranica za detalje o podršci.
Image: A graphic highlighting the 24-month support and warranty provided by AsperX for this product.
