Uvod
This manual provides comprehensive instructions for setting up, operating, and maintaining your Bmax Mini PC B9 Power. This high-performance mini desktop computer is equipped with an Intel Core i9-12900HK processor, 32GB DDR4 RAM, and a 1TB NVMe SSD, designed for efficient multitasking, gaming, and multimedia consumption. It supports triple 4K/60Hz display output and features advanced cooling technology.
Slika: Prednja i zadnja strana view of the Bmax Mini PC B9 Power, showcasing svojim kompaktnim dizajnom i raznim priključcima.
Šta je u kutiji
- 1 x B9 Power MINI PC
- 1 x HDMI kabl
- 1 x Korisnički priručnik (ovaj dokument)
- 1 x američki adapter za napajanje
- 1 x VESA nosač sa vijcima
Vodič za postavljanje
1. Connecting Your Mini PC
Follow these steps to connect your Bmax Mini PC B9 Power to your display and peripherals:
- Poveži se sa ekranom: Use the provided HDMI cable to connect the Mini PC's HDMI port to your monitor or TV. Alternatively, you can use the DisplayPort (DP) or Type-C port for video output. This Mini PC supports up to three 4K/60Hz displays simultaneously.
- Povežite periferne uređaje: Priključite USB tastaturu i miš u dostupne USB 3.2 ili USB 2.0 portove.
- Povežite se na mrežu: For wired internet, connect an Ethernet cable to the RJ45 port. For wireless internet, the device supports WiFi 6.
- Priključak za napajanje: Connect the US Power Adapter to the DC Power Port on the Mini PC, then plug the adapter into a power outlet.
Slika: Detaljna view of the Bmax Mini PC's ports, including USB 3.2, USB 2.0, Type-C, HDMI 2.1, DisplayPort 1.4a, RJ45, 3.5mm Audio Jack, and DC Power In.
2. Početno uključivanje
After connecting all necessary cables, press the power button located on the front of the Mini PC. The system will boot up, and you will see the operating system interface on your connected display.
3. Instalacija VESA nosača (opciono)
The Bmax Mini PC B9 Power comes with a VESA mount, allowing you to attach it to the back of a compatible monitor or to a wall, saving desk space.
- Attach the VESA mount bracket to the back of your monitor or desired wall location using the provided screws.
- Slide the Mini PC onto the VESA mount until it clicks securely into place.
Image: Demonstrates various space-saving installation options, including mounting behind a monitor or placing on a desk.
Uputstvo za upotrebu
System Overview
The Bmax Mini PC B9 Power is pre-installed with an operating system (OS) and is ready for use upon initial setup. It features a powerful Intel Core i9-12900HK processor, 32GB DDR4 RAM, and a 1TB NVMe SSD for high-speed performance and ample storage.
Image: An infographic highlighting key features such as Intel Core i9-12900HK, Intel Iris Xe Graphics, 32GB DDR4, 1TB NVMe SSD, Space Capsule Cooling System, triple display support, WiFi 6, Bluetooth 5.2, USB ports, 4K/60Hz support, Linux (Ubuntu) support, and pre-installed Windows 11.
Procesor i performanse
Equipped with the Intel Core i9-12900HK processor, featuring 14 cores and 20 threads with a max turbo frequency of 5.00GHz, this Mini PC delivers exceptional performance for demanding applications, multitasking, and gaming. The 32GB DDR4 memory ensures smooth operation even with multiple applications running simultaneously.
Image: Visual representation of the Intel Core i9-12900HK processor's specifications, including 14 cores, 20 threads, Intel 7 lithography, 24MB Intel Smart Cache, and 5.00GHz Max Turbo Frequency. Also shows a performance comparison chart.
Skladištenje i memorija
The 1TB NVMe SSD provides rapid boot times and quick application loading, significantly faster than traditional SSDs. The 32GB DDR4 RAM (3200MHz) ensures ample memory for all your computing needs, from office tasks to creative work and entertainment.
Image: Depicts the Mini PC handling various applications like Hulu, Photoshop, AI, After Effects, Word, Excel, and PowerPoint, alongside multimedia tasks such as listening to music, playing games, and watching movies, emphasizing its ability to accommodate massive files.
Mogućnosti prikaza
The Mini PC supports triple 4K@60Hz display outputs via HDMI 2.1, USB-C (full features), and DisplayPort. This allows for an expansive workspace, ideal for professional use, multi-monitor gaming, or a home theater setup.
Image: Shows the Mini PC connected to three monitors, demonstrating its triple 4K@60Hz output capability for an enhanced visual experience.
Povezivanje
The B9 Power features built-in 802.11a/b/g/n/ac/ax WiFi 6 for high-speed wireless networking and Bluetooth 5.2 for connecting wireless peripherals like headsets, mice, and keyboards.
Image: A comparison chart illustrating the speed advantages of WiFi 6 over WiFi 5, showing faster speeds, higher throughput, and lower latency.
Zvanični video proizvoda
Video: An official product video from BMAX Tech showcasing the features and capabilities of the Bmax Mini PC B9 Power, including its processor, memory, storage, cooling, and connectivity options. (Duration: 0:40)
Održavanje
Sistem za hlađenje
The B9 Power features a "Space Capsule Cooling System" with an enlarged double copper heat pipe and a high-performance turbo smart fan. This design ensures efficient heat dissipation, maintaining stable performance even under heavy workloads.
Image: Illustrates the internal cooling components, including the giant turbo smart fan and enlarged double copper cooling pipe, highlighting the efficient heat dissipation design.
Opća njega
- Keep the Mini PC in a well-ventilated area to ensure optimal airflow.
- Avoid blocking the ventilation holes on the device.
- Clean the exterior of the Mini PC regularly with a soft, dry cloth. Do not use liquid cleaners.
- Periodically check for dust accumulation in the vents and gently clean with compressed air if necessary.
Rješavanje problema
Smart Recovery System
The Bmax Mini PC B9 Power includes a unique "Smart Recovery" feature to help resolve operating system issues, such as crashes, slow response, or problems during OS upgrades. This allows you to quickly reset your system to its factory settings.
Image: The Smart Recovery screen, offering options for "Factory Reset" and "Exit". Instructions indicate connecting a USB mouse or pressing 'Y' for factory reset and 'E' to exit. A warning notes that recovery will erase all data and requires power connection.
To access the Smart Recovery Environment:
- Ensure the Mini PC is connected to a power source.
- Connect a USB mouse to navigate the recovery menu.
- Follow the on-screen instructions to perform a "Factory Reset" or "Exit" to the system.
- Upozorenje: A factory reset will erase all data on the drive. Back up important files pre nego što nastavite.
Uobičajeni problemi i rješenja
| Issue | Mogući uzrok | Rješenje |
|---|---|---|
| Nema izlaza na ekranu | Incorrect cable connection, monitor input not selected, power issue. | Check HDMI/DP/Type-C cable connections. Ensure monitor is on and set to correct input source. Verify power adapter is securely connected. |
| Nema struje | Power adapter not connected, faulty outlet. | Ensure power adapter is fully plugged into the Mini PC and a working power outlet. Try a different outlet. |
| Wi-Fi se ne povezuje | Incorrect Wi-Fi password, router issue, driver problem. | Verify Wi-Fi password. Restart your router. Check device manager for Wi-Fi driver status. |
| System slow/unresponsive | Previše pokrenutih aplikacija, malo prostora na disku, zlonamjerni softver. | Close unnecessary applications. Free up disk space. Run a system scan for malware. Consider using the Smart Recovery feature if issues persist. |
Specifikacije
| Feature | Detalj |
|---|---|
| Procesor | Intel Core i9-12900HK (up to 5.0GHz, 14 Cores/20 Threads) |
| Grafika | Intel Iris Xe Graphics (1.45Ghz) |
| RAM | 32GB DDR4 (3200MHz) |
| Skladištenje | 1TB NVMe SSD |
| Video izlaz | HDMI 2.1 (4K@60Hz), DisplayPort (DP), Type-C (full features) - Supports Triple Display |
| Bežično povezivanje | WiFi 6 (802.11a/b/g/n/ac/ax), Bluetooth 5.2 |
| Žičano povezivanje | RJ45 Ethernet |
| USB portovi | 2 x USB 3.2, 2 x USB 2.0, 1 x Type-C (full features) |
| Audio | 1 x 3.5-mm Stereo Headset Jack |
| Operativni sistem | Pre-installed OS (as per product description, likely Windows 11) |
| Sistem za hlađenje | Space Capsule Cooling System (Giant Turbo Smart Fan, Enlarged Double Copper Heat Pipe) |
| Dimenzije | 11.02 x 6.18 x 2.91 inča (dimenzije pakovanja) |
| Težina | 1.83 funte |
Garancija i podrška
Bmax offers a 12-month warranty for the B9 Power Mini PC. For technical support, warranty claims, or any product-related inquiries, please contact Bmax customer service through their official channels or the retailer where the product was purchased.
You can visit the official Bmax store on Amazon for more information and support resources: Bmax Amazon Store
