1. Uvod
The EARMOR M300T Electronic Shooting Ear Protection is designed to provide reliable hearing protection in noisy environments while maintaining situational awareness and communication capabilities. This headset features advanced digital signal processing, Bluetooth 5.4 connectivity, and multiple sound pickup modes to enhance user experience and safety.
Figure 1: EARMOR M300T Electronic Shooting Ear Protection Earmuffs.
2. Ključne karakteristike
- Bluetooth 5.4 povezivanje: Enables seamless connection for calls and audio streaming with enhanced stability and range.
- 29dB SNR / 22dB NRR Hearing Protection: ANSI-certified to block harmful noise above 82dB within 0.001 seconds, ideal for shooting and loud environments.
- 360° Sound Tracking & 4X Hearing Enhancement: Smart acoustic technology for omnidirectional sound pickup and ambient sound amplification, with instant noise suppression.
- Three Unique Pickup Modes:
- Način fokusa: Boosts bullet impact sounds for enhanced focus.
- Način jasnog glasa: Optimizes ambient sound processing to prioritize human speech, facilitating clear communication.
- Ambijentalni način rada: Amplifies all subtle ambient sounds for increased overall situational awareness.
- Ergonomski i izdržljiv dizajn: Lightweight (approximately 0.67 lb) with low-profile ear cups, soft headband, and high-quality gel ear pads for comfort and durability.
- IPX5 vodootporna ocjena: Ensures durability in various weather conditions.
- Automatsko isključivanje: Automatically powers off after 4 hours of inactivity to conserve battery.
Figure 2: Illustration of the three unique pickup modes.
3. Components Overview
The EARMOR M300T headset consists of the following main components:
- Traka za glavu: Adjustable for fit, with soft padding for comfort.
- Ear Cups: House the electronic components and provide noise reduction.
- Gel Ear Pads: Soft, comfortable, and provide an effective seal.
- Dugme za napajanje/glasnoću: Rotary switch for turning the unit on/off and adjusting volume.
- Dugme za odabir načina rada: For switching between sound pickup modes.
- mikrofoni: External microphones for ambient sound pickup.
- Pretinac za baterije: Located on one of the ear cups.
Figure 3: EARMOR M300T components and comfort features.
4. Podešavanje i ugradnja baterija
4.1 Instalacija baterije
The EARMOR M300T requires two (2) AAA batteries (not included) for operation. Follow these steps to install the batteries:
- Locate the battery compartment cover on one of the ear cups.
- Gently pry open the cover.
- Umetnite dvije AAA baterije, pazeći na ispravan polaritet (+/-).
- Replace the battery compartment cover, pressing firmly until it clicks into place.
Video 1: Demonstrates battery installation and basic operation of the EARMOR M300T5.4 earmuffs.
4.2 Wearing and Adjustment
For optimal hearing protection and comfort, ensure the earmuffs are worn correctly:
- Extend the headband and place the ear cups over your ears.
- Adjust the headband until it rests comfortably on the top of your head and the ear cups fully enclose your ears, creating a tight seal.
- Ensure no hair or clothing interferes with the ear pad seal.
5. Uputstvo za upotrebu
5.1 Uključivanje/isključivanje i kontrola jačine zvuka
The power and volume are controlled by the rotary knob on the right ear cup:
- Za uključivanje: Rotate the knob clockwise until you hear a click and the unit powers on.
- Za podešavanje glasnoće: Continue rotating the knob clockwise to increase volume or counter-clockwise to decrease volume.
- Za isključivanje: Rotate the knob counter-clockwise until you hear a click and the unit powers off.
5.2 Odabir načina rada
The EARMOR M300T offers three distinct sound pickup modes. Press the mode selection button (located near the power knob) to cycle through them:
- Način fokusa: Designed to emphasize sharp, sudden sounds like bullet impacts, aiding in shooting practice.
- Način jasnog glasa: Optimizes ambient sound processing to prioritize human speech, facilitating clear communication.
- Ambijentalni način rada: Amplifies all subtle ambient sounds, enhancing overall situational awareness.
6. Bluetooth povezivanje
The M300T features Bluetooth 5.4 for wireless audio streaming and call management.
6.1 Uparivanje s uređajem
- Ensure the earmuffs are powered on.
- Activate Bluetooth on your mobile device or other audio source.
- Traži available Bluetooth devices. The earmuffs should appear as "EARMOR M300T" or similar.
- Select the earmuffs to initiate pairing. A voice prompt or indicator light will confirm successful pairing.
- The LED indicator will blink during connection and automatically shut off after pairing to reduce signal interference.
6.2 Answering/Rejecting Calls
When connected via Bluetooth, you can manage phone calls directly from the earmuffs. Refer to your device's manual for specific call control functions, as these may vary.
Figure 4: Bluetooth 5.4 for seamless connectivity.
7. Održavanje i njega
Proper maintenance ensures the longevity and performance of your EARMOR M300T earmuffs.
- čišćenje: Wipe the ear cups and headband with a damp cloth. Do not use harsh chemicals or abrasive cleaners. The manufacturer recommends dry cleaning for fabric components.
- Skladištenje: When not in use, fold the earmuffs for compact storage. Store in a cool, dry place away from direct sunlight and extreme temperatures.
- Jastučići za uši: Regularly inspect gel ear pads for wear and tear. Replace them if they become damaged to maintain optimal noise reduction and comfort.
- baterije: Remove batteries if the earmuffs will not be used for an extended period to prevent leakage.
Figure 5: Gel ear pads for enhanced comfort and seal.
8. Otkrivanje problema
If you encounter issues with your EARMOR M300T, refer to the following common problems and solutions:
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Nema struje | Prazne ili nepravilno instalirane baterije. | Replace batteries with fresh AAA batteries, ensuring correct polarity. |
| Nema zvuka amplifikacija | Volume too low; microphones blocked; unit off. | Increase volume; ensure microphones are clear; power on the unit. |
| Bluetooth se ne povezuje | Slušalice nisu u načinu uparivanja; Bluetooth uređaja isključen; previše udaljeno od uređaja. | Ensure earmuffs are on; enable Bluetooth on device; move closer to device; try re-pairing. |
| Poor noise reduction | Improper fit; worn ear pads. | Adjust headband for a snug fit; ensure no gaps around ears; replace ear pads if damaged. |
9. Specifikacije
| Feature | Detalj |
|---|---|
| Broj modela | M300T |
| Ocjena smanjenja buke (NRR) | 22dB |
| Odnos signala i buke (SNR) | 29dB |
| Bluetooth verzija | 5.4 |
| Izvor napajanja | 2 x AAA baterije (nisu uključene) |
| Waterproof Rating | IPX5 |
| Težina | Approximately 0.67 lb (304g) |
| Ear Pad Material | Soft silicone gel, memory foam |
| Materijal školjke | Upgrade ABS |
Figure 6: EARMOR M300T certifications.
10. Sigurnosne informacije
Always prioritize safety when using hearing protection devices:
- Ensure the earmuffs fit snugly and create a complete seal around your ears to achieve stated noise reduction levels.
- Do not modify the earmuffs, as this may compromise their protective capabilities.
- Držite baterije van domašaja dece.
- Avoid exposing the earmuffs to extreme heat or open flames.
- If you experience discomfort or hearing issues while using the product, discontinue use and consult a professional.
11. Garancija i podrška
For warranty information, technical support, or replacement parts, please contact EARMOR customer service through their official webweb-mjestu ili prodavaču gdje je proizvod kupljen.
Manufacturer: EARMOR OFFICIAL
