1. Proizvod je gotovview
The Alcatel XL685 is a DECT cordless fixed phone designed for ease of use, particularly for seniors. It combines essential telephony features with enhanced accessibility options.
- XL Format Fixed Phone: Features a large, high-contrast white backlit graphic display, large, ultra-readable characters, contrasting large keys, and a luminous indicator for incoming calls.
- Audio Amplification & Hands-Free: Hearing aid compatible, equipped with a loud ringer, an audio boost button that doubles the sound volume with one click (+10dB) up to a maximum of 25dB, and an adjustable hands-free volume for clear conversations.
- Upravljanje kontaktima: Stores up to 100 contacts in its directory, keeps a log of the last 50 calls, and includes two keys for quick access to favorite numbers.
- Unwanted Call Blocking: Block up to 100 unwanted numbers using a dedicated key. An automatic mode allows only registered contacts to ring, blocking 100% of anonymous calls.
Figure 1: Alcatel XL685 DECT Cordless Phone with large display and keys.
2. Šta se nalazi u kutiji
Provjerite da li su sve stavke prisutne u paketu:
- Alcatel XL685 mobilni telefon
- Base Station
- Adapter za napajanje
- Telefonski kabel
- Uputstvo za upotrebu
3. Podešavanje
3.1. Povezivanje bazne stanice
- Connect the telephone line cable to the socket on the base station and to your telephone wall socket.
- Spojite adapter za napajanje na baznu stanicu i uključite ga u utičnicu.
- Place the handset on the base station to charge the battery. Ensure the handset is properly seated.
3.2. Ugradnja i punjenje baterije
- Otvorite poklopac odeljka za baterije na poleđini slušalice.
- Insert the supplied NiMH batteries, observing the correct polarity (+/-).
- Zatvorite poklopac odeljka za baterije.
- For optimal performance, charge the handset for at least 15 hours before initial use.
Figure 2: Connecting the Alcatel XL685 phone and its accessories.
4. Uputstvo za upotrebu
4.1. Upućivanje i primanje poziva
- Pozivanje: Dial the number and press the green call button (📞).
- Primanje poziva: Kada telefon zazvoni, pritisnite zeleno dugme za poziv (📞).
- Završetak poziva: Pritisnite crveno dugme za prekid poziva (☎️) or place the handset back on the base.
- Hands-free: Tokom poziva, pritisnite dugme za handsfree da biste aktivirali ili deaktivirali zvučnik. Podesite jačinu zvuka pomoću navigacijskih tipki.
4.2. Using the Audio Boost Function
The Audio Boost function increases the receiver volume for users with hearing difficulties.
- During a call, press the dedicated Audio Boost button (often marked with an ear icon or '+').
- The volume will increase by +10dB, up to a maximum of 25dB.
4.3. Managing Contacts (Directory)
- Dodavanje kontakta: Navigate to the 'Directory' menu, select 'Add New', enter the name and number, then save.
- Speed Dial Keys (M1, M2): Assign frequently called numbers to the M1 and M2 buttons for one-touch dialing. Refer to the detailed manual for programming steps.
- Spisak poziva: Access the call log to view the last 50 incoming, outgoing, and missed calls.
4.4. Call Blocking Features
The XL685 offers robust call blocking to enhance your peace of mind.
- Ručno blokiranje: During or after a call from an unwanted number, press the dedicated call blocking button (often marked with a 'STOP' or '🚫' icon) to add the number to the block list. Up to 100 numbers can be blocked.
- Automatsko blokiranje: Activate the automatic blocking mode via the phone's menu. In this mode, only numbers saved in your directory will be able to ring through. All other calls, including anonymous ones, will be blocked.
Figure 3: Call blocking features on the Alcatel XL685.
4.5. Navigacija kroz ekran i meni
- The large graphic display shows caller ID, menu options, and phone status.
- Use the navigation keys (up/down arrows) to scroll through menu options.
- Press the 'OK' or 'Menu' button to confirm selections or enter the main menu.
Figure 4: Key features of the Alcatel XL685 for enhanced usability.
5. Održavanje
- čišćenje: Koristite meku, damp krpu za čišćenje slušalice i bazne stanice. Ne koristite abrazivna sredstva za čišćenje ili rastvarače.
- Održavanje baterije: Replace batteries when their performance significantly degrades. Use only recommended NiMH battery types.
- Uslovi okoline: Izbjegavajte izlaganje telefona ekstremnim temperaturama, direktnoj sunčevoj svjetlosti ili vlazi.
6. Otkrivanje problema
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Nema tona za biranje | Phone line cable not connected or faulty. | Check phone line connections. Test with another phone if possible. |
| Slušalica se ne puni | Handset not correctly placed on the base, dirty charging contacts, or faulty battery. | Provjerite je li slušalica pravilno postavljena. Očistite kontakte za punjenje. Po potrebi zamijenite baterije. |
| Loš kvalitet poziva | Out of range from base, interference, or low battery. | Move closer to the base. Avoid other electronic devices. Charge handset battery. |
| Cannot block calls | Call blocking feature not activated or incorrect settings. | Refer to section 4.4 for call blocking instructions. Ensure the feature is enabled. |
7. Specifikacije
| Feature | Detalj |
|---|---|
| Brand | Alcatel |
| Broj modela | XL685 |
| Boja | Bijelo |
| Vrsta telefona | Bežični |
| Kompatibilni uređaji | Standard Telephone Network (PSTN), Potentially other common telephone networks |
| Vrsta baterije | NiMH |
| Broj baterija | 2 AAA (uključeno) |
| Materijal | Plastika |
| Izvor napajanja | Battery Powered |
| Tip sistema za odgovor | Digital (if applicable to specific variant) |
| Višelinijski rad | Jednolinijski rad |
| Caller ID | Da |
8. Garancija i podrška
The Alcatel XL685 comes with a 2-godišnja garancija proizvođača. For technical support, troubleshooting assistance, or warranty claims, please contact Alcatel customer service or refer to the official Alcatel webstranica za kontakt informacije.
Molimo sačuvajte dokaz o kupovini u svrhu garancije.
9. Dodatni resursi
9.1. Videozapisi proizvoda
Alcatel TMAX 10 - Corded Phone with Large Keys for Seniors
This video demonstrates the features of the Alcatel TMAX 10, a corded phone with large keys designed for seniors, showcasing similar accessibility features to the XL685.
Video sažetak proizvoda
A brief video summarizing the key aspects and benefits of the Alcatel XL685 phone.
9.2. Slike proizvoda
Figure 5: Close-up of the Alcatel XL685's large display and keypad.
Slika 6: Bočna strana view of the Alcatel XL685 cordless phone, highlighting its ergonomic design.
Figure 7: Another perspective of the Alcatel XL685 cordless phone.
Figure 8: Features for easy calling and enhanced audio on the Alcatel XL685.
Figure 9: The Alcatel XL685, designed with large keys and display for seniors.
Figure 10: Key features of the Alcatel XL685 including ECO-DECT and Audio-Boost.
Figure 11: Comparison of Alcatel XL685 and XL595 models, highlighting available configurations.
