TMY Native 1080P Mini Projector User Manual

1. Uvod

This manual provides detailed instructions for the setup, operation, and maintenance of your TMY Native 1080P Mini Projector. Please read this manual thoroughly before using the projector to ensure proper function and longevity.

2. Šta se nalazi u kutiji

• TMY Native 1080P Mini Projector
• Daljinski upravljač
• Kabl za napajanje
• HDMI kabl
• Uputstvo za upotrebu
• Komplet za čišćenje

3. Proizvod je gotovview

The TMY Native 1080P Mini Projector is designed for versatile home entertainment, offering native 1080P resolution and various connectivity options in a compact form factor.

3.1 Portovi za povezivanje

The projector features multiple ports for connecting various devices:

• HDMI priključak: For connecting devices such as TV sticks, PCs, gaming consoles, and DVD players.
• USB port: Za povezivanje USB diskova za reprodukciju medija files.
• 3.5 mm audio priključak: For connecting external wired speakers or headphones.
• Ulazna snaga: Za spajanje kabla za napajanje.

4. Podešavanje

4.1 Postavljanje

Position the projector on a stable, flat surface. The projection distance can range from 1.5 meters to 5 meters, producing a screen size from 40 inches to 200 inches. Ensure there are no obstructions between the projector and the projection surface.

4.2 Priključak za napajanje

1. Spojite kabel za napajanje na ulazni priključak za napajanje projektora.
2. Uključite drugi kraj kabla za napajanje u utičnicu.

4.3 Početno uključivanje

Pritisnite dugme za napajanje na projektoru ili daljinskom upravljaču da biste uključili uređaj. Indikatorska lampica će se upaliti.

4.4 Fokus i korekcija trapezoidnog izobličenja

To achieve a clear and rectangular image, adjust the focus ring and keystone correction dial located on the projector. The projector supports ±15° vertical keystone correction.

5. Uputstvo za upotrebu

5.1 Povezivanje uređaja

The projector offers multiple ways to connect your devices:

5.1.1 HDMI veza

Connect your device (e.g., TV Stick, PC, gaming console) to the projector's HDMI port using an HDMI cable. Select the corresponding HDMI input source from the projector's menu.

5.1.2 USB veza

Insert a USB drive into the USB port. Navigate to the media player function in the projector's menu to browse and play files.

5.1.3 WiFi veza (zrcaljenje ekrana)

The projector supports 5G/2.4G dual-band WiFi for wireless screen mirroring from compatible smartphones, tablets, and laptops. Access the WiFi settings in the projector's menu to connect to your home network and initiate screen mirroring.

5.1.4 Bluetooth veza

The projector features two-way Bluetooth 5.2 technology. It can connect to external Bluetooth speakers or headphones for audio output. Additionally, it can function as a Bluetooth speaker itself, allowing you to connect your smartphone or tablet to play audio through the projector's built-in speakers.

Napomena:

• Bluetooth does not support screen mirroring with your phone.
• When connecting to external Bluetooth speakers, ensure the speaker is in pairing mode.

5.2 Funkcija zumiranja

The projector includes a 100% to 50% zoom function, allowing you to adjust the screen size digitally without physically moving the projector. This feature is accessible through the projector's menu settings.

5.3 Navigacija izbornikom

Use the remote control to navigate through the projector's on-screen menu. The menu allows you to select input sources, adjust picture settings (brightness, contrast, color), sound settings, and other system configurations.

6. Održavanje

6.1 Čišćenje

• Objektiv: Use the provided cleaning cloth or a soft, lint-free cloth to gently wipe the projector lens. Avoid abrasive materials.
• Eksterijer: Wipe the projector's exterior with a soft, dry cloth. Do not use liquid cleaners or solvents.
• Ventilacijski otvori: Periodically check and clean the air vents to ensure proper airflow and prevent overheating.

6.2 Skladištenje

Kada se ne koristi, projektor čuvajte na hladnom i suhom mjestu, dalje od direktne sunčeve svjetlosti i ekstremnih temperatura. Koristite originalno pakovanje ili zaštitnu futrolu kako biste spriječili nakupljanje prašine i oštećenja.

7. Otkrivanje problema

• Nema napajanja: Ensure the power cord is securely connected to both the projector and the power outlet. Check if the power outlet is functional.
• Nema slike: Verify that the correct input source is selected in the projector's menu. Check all cable connections (HDMI, USB).
• Zamućena slika: Adjust the focus ring on the projector until the image is clear. Ensure the projection distance is within the recommended range.
• Slika nije pravougaona: Use the keystone correction dial to adjust the image until it appears rectangular.
• Nema zvuka: Check the volume settings on both the projector and the connected device. If using external speakers, ensure they are properly connected and powered on.
• Sound/Video Lag: For screen mirroring, ensure a stable WiFi connection. For wired connections, try a different cable or port. Note that Bluetooth does not support screen mirroring and may introduce slight audio delay with external speakers.
• pregrijavanje: Ensure the projector's air vents are not blocked. Operate the projector in a well-ventilated area.

8. Specifikacije

9. Garancija i podrška

For warranty information or technical support, please refer to the warranty card included in your product packaging or contact TMY customer service directly. Contact details can typically be found on the official TMY webweb-stranice ili putem vaše platforme za kupovinu.
