1. Uvod
Welcome to the user manual for your new DOOGEE Blade 10 Ultra (2025) Rugged Smartphone. This manual provides essential information on setting up, operating, and maintaining your device. Designed for durability and high performance, the Blade 10 Ultra is built to withstand challenging environments while offering advanced smartphone capabilities.
Slika: Prednja i zadnja strana view of the DOOGEE Blade 10 Ultra (2025) Rugged Smartphone, showcasing svojim robusnim dizajnom i modulom kamere.
2. Sadržaj paketa
Molimo označite kućicu za sljedeće stavke:
- DOOGEE Blade 10 Ultra Smartphone
- USB kabel
- Zaštitna torbica
- Zaštitna folija za ekran (unaprijed postavljena ili u kutiji)
3. Značajke proizvoda
3.1. Performanse i pohrana
The DOOGEE Blade 10 Ultra is equipped with a powerful Octa-core Processor (1.6GHz) for smooth operation. It features 20GB RAM (8GB physical + 12GB virtual) and 256GB of internal storage, expandable up to 2TB via a microSD card (sold separately).
Image: Visual representation of the 20GB RAM and 256GB ROM, highlighting the expandable storage via microSD card.
3.2. Displej
Experience vibrant visuals on the 6.56-inch HD+ Waterdrop Display with a 90Hz refresh rate. Utilizing TDDI technology, the display offers enhanced touch sensitivity and clarity. Key display specifications include:
- Veličina: 6.56 inča
- rezolucija: 1080 x 2400
- Brzina osvježavanja: 90Hz
- Omjer ekrana i tijela: 90%
- Omjer širine i visine: 20:9
- boje: 16.7 miliona
- Svjetlina: 400 nita
- Kontrast: 1500:1
Image: Close-up of the 6.56-inch HD+ 90Hz Waterdrop Display, highlighting its visual quality and specifications.
3.3. Sistem kamera
Capture clear photos with the 50MP AI Main Camera and take selfies with the 8MP Front Camera.
Image: Illustration of the smartphone's camera setup, featuring the 50MP AI main camera and 8MP front camera.
3.4. Baterija
The device is powered by a 5150mAh Lithium Polymer battery, providing extended usage time.
Image: Depiction of the 5150mAh battery, emphasizing its capacity for longer usage.
3.5. Operativni sistem
The DOOGEE Blade 10 Ultra runs on the latest Android 14 OS, offering enhanced security, privacy features, and a user-friendly interface.
Image: Android 14 operating system interface with various app icons, indicating the phone's software version.
4. Podešavanje
4.1. Umetanje SIM kartica i MicroSD kartice
The DOOGEE Blade 10 Ultra supports dual SIM cards and a microSD card for expanded storage. Locate the SIM tray on the side of the device. Use the provided SIM ejector tool to open the tray. Carefully place your Nano-SIM cards and/or microSD card into the designated slots, ensuring correct orientation. Close the tray securely.
Image: Diagram illustrating the insertion of dual SIM cards and a TF (microSD) card into the phone's tray.
4.2. Početno uključivanje i čarobnjak za podešavanje
Press and hold the Power button until the DOOGEE logo appears. Follow the on-screen instructions to complete the initial setup, including language selection, Wi-Fi connection, Google account login, and security settings (Face ID, Fingerprint Recognition, PIN/Pattern).
5. Uputstvo za upotrebu
5.1. Unlocking Your Device
The Blade 10 Ultra offers multiple unlocking methods:
- Side Fingerprint Recognition: The fingerprint sensor is integrated into the side power button. Register your fingerprints in the Security settings for quick and secure unlocking (0.19s response speed, 508DPI scanning resolution, 360° identification angle).
- Prepoznavanje lica: Set up Face ID for instant access by simply looking at your phone.
- PIN/Uzorak/Lozinka: Standard Android unlocking methods.
Image: Illustration showing the side fingerprint recognition and face recognition features for unlocking the device.
5.2. Osnovna navigacija
Navigate the Android 14 interface using gestures or the traditional navigation bar. Swipe up from the bottom to access the app drawer, swipe down from the top for quick settings and notifications.
Video: A demonstration of the DOOGEE Blade 10 Ultra's various back cover designs and its slim profile.
5.3. Multimedija i zabava
The Blade 10 Ultra supports Widevine L1, allowing you to stream high-definition content from platforms like Hulu, Amazon Prime Video, and HBO Max.
Image: Illustration of Widevine L1 support, showing logos for Hulu, Amazon Prime Video, and HBO Max, indicating high-definition streaming capability.
Video: Krajview of the DOOGEE Blade 10 series, emphasizing its ruggedness and reliability.
5.4. Povezivanje
Uređaj nudi sveobuhvatne mogućnosti povezivanja:
- Wi-Fi: Supports dual-band Wi-Fi for fast and stable internet connection.
- mobilni: Unlocked for all carriers, supporting 4G networks.
- NFC: Za beskontaktna plaćanja i prijenos podataka.
- GPS: Za precizne navigacijske i lokacijske usluge.
5.5. Digital Toolkit
The Blade 10 Ultra includes a useful digital toolkit with various utility applications:
- Kompas
- Merač zvuka
- Vješanje slika
- Gradienter
- Weight Measure
- Protractor
- Plumb Bob
- Lupa
- Alarm Bell
6. Izdržljivost i njega
The DOOGEE Blade 10 Ultra is built to be rugged, featuring IP68, IP69K, and MIL-STD-810H certifications, making it highly resistant to water, dust, and drops.
- IP68: Otporan na vodu i prašinu.
- IP69K: Otporan na mlazove vode visokog pritiska i visoke temperature.
- MIL-STD-810H: Vojni standard za izdržljivost na padove, udarce i ekstremne temperature.
Image: Visual representation of the phone's IP68, IP69K, and MIL-STD-810H ratings, demonstrating its resistance to water, dust, and drops.
While rugged, proper care is still recommended to ensure longevity. Avoid exposing the device to extreme conditions beyond its specified ratings. Ensure all port covers are securely closed before exposing the phone to water or dust.
Video: A detailed look at the transparent back cover of the DOOGEE Blade 10 Ultra, showcasing svojim jedinstvenim dizajnom.
7. Održavanje
- čišćenje: Koristite meku, damp krpu za čišćenje uređaja. Izbjegavajte jake hemikalije ili abrazivne materijale.
- Ažuriranja softvera: Redovno provjeravajte i instalirajte ažuriranja sistema kako biste osigurali optimalne performanse i sigurnost. Idite na Postavke > Sistem > Ažuriranje sistema.
- Održavanje baterije: To prolong battery life, avoid extreme temperatures and do not fully discharge the battery frequently.
8. Otkrivanje problema
| Problem | Moguće rješenje |
|---|---|
| Uređaj se ne uključuje | Ensure the battery is charged. Connect to a charger for at least 10 minutes. If still unresponsive, perform a forced restart by holding the Power button for 10-15 seconds. |
| Loš mrežni signal | Check if SIM card is properly inserted. Move to an area with better network coverage. Restart the device. |
| Aplikacije se ruše ili zamrzavaju | Clear app cache (Settings > Apps > [App Name] > Storage > Clear cache). Restart the device. Update the app or reinstall it. |
| Senzor otiska prsta ne radi | Provjerite je li vaš prst čist i suh. Ponovo registrirajte otiske prstiju u Postavkama > Sigurnost. |
| Charging port flap issue | The charging port is covered by a rubber cap for waterproofing. Ensure it is fully opened when charging and securely closed afterwards. Handle with care to prevent damage. |
9. Specifikacije
| Feature | Specifikacija |
|---|---|
| Model | Blade 10 Ultra |
| Operativni sistem | Android 14 |
| RAM | 20 GB (8 GB fizičke + 12 GB virtuelne) |
| Interna pohrana | 256GB |
| Proširiva pohrana | Up to 2TB microSD card |
| Veličina ekrana | 6.56 inča |
| Rezolucija ekrana | 1080 x 2400 |
| Refresh Rate | 90Hz |
| Glavna kamera | 50MP AI kamera |
| Prednja kamera | 8MP |
| Kapacitet baterije | 5150mAh |
| Ocjene izdržljivosti | IP68, IP69K, MIL-STD-810H |
| Povezivanje | Wi-Fi, Cellular (4G), NFC, GPS |
| Metode otključavanja | Side Fingerprint, Face Recognition |
| Dimenzije | 7.64 x 4.09 x 2.24 inča |
| Težina | 9.2 unci (262 grama) |
| Audio Jack | Nema priključka za slušalice |
10. Garancija i podrška
For warranty information and technical support, please refer to the official DOOGEE webweb-mjesto ili direktno kontaktirajte njihovu korisničku službu. Sačuvajte dokaz o kupovini za slučaj reklamacije.
