Cuifati 5G mobilna WiFi pristupna tačka i 10000mAh prenosna baterija (Power Bank) - uputstvo za upotrebu

1. Proizvod je gotovview

The Cuifati 5G Mobile WiFi Hotspot is a versatile 2-in-1 device, combining a high-speed 5G WiFi hotspot with a 10000mAh power bank. It is designed to provide reliable internet connectivity and portable power for up to 16 devices simultaneously, supporting global network bands.

Ključne karakteristike:

• Global Network Support: Operates in over 50 5G countries and 100+ operator networks, including major 4G networks.
• Integrisana prenosna baterija: Features a 10000mAh battery for charging other devices on the go.
• Povezivanje na više uređaja: Connects up to 16 devices simultaneously, offering superior Wi-Fi performance.
• Brza veza: Delivers 5G Wi-Fi speeds up to 2.5 Gbps, significantly faster than 4G.
• Svestrana upotreba: Suitable for home, business, travel, and various outdoor activities.

Slika 1: Prednja strana view of the Cuifati 5G Mobile WiFi Hotspot, showing indicator lights for signal strength and battery.

2. Sadržaj paketa

Molimo Vas da provjerite paket za sljedeće stavke:

• 1 x Cuifati 5G WiFi Host
• 1 x USB podatkovni kabel (tip-C)
• 1 x Uputstvo za upotrebu

Figure 2: The Cuifati 5G Mobile WiFi Hotspot device and its included USB Type-C data cable.

3. Device Layout and Function Keys

Figure 3: Diagram illustrating the key components and ports of the device.

• Tip-C konektor: Used for charging the device and for its power bank function.
• Indikatorsko svjetlo: Displays network status (4G/5G), Wi-Fi activity, and battery level.
• Tipka za uključivanje/isključivanje: Uključuje ili isključuje uređaj.
• Reset ključ: Koristi se za vraćanje na fabričke postavke (obično malo dugme sa rupicom).
• SIM Card Insertion Port: Slot for inserting your Nano SIM card.

4. Upute za postavljanje

4.1. Umetanje SIM kartice

1. Uvjerite se da je uređaj isključen.
2. Locate the SIM Card Insertion Port (refer to Figure 3).
3. Gently insert a Nano SIM card into the slot with the gold contacts facing down, until it clicks into place.
4. Close the SIM card slot cover (if applicable).

4.2. Punjenje uređaja

1. Connect the provided USB Type-C data cable to the device's Type-C connector.
2. Drugi kraj kabla priključite na kompatibilni USB adapter za napajanje (nije uključen) ili USB port računara.
3. The battery indicator light will show charging status. Charge the device fully before first use.

5. Uputstvo za upotrebu

5.1. Uključivanje / isključivanje napajanja

• Za uključivanje: Press and hold the On/Off Key for a few seconds until the indicator lights illuminate.
• Za isključivanje: Press and hold the On/Off Key for a few seconds until the indicator lights turn off.

5.2. Connecting Devices to WiFi

1. Provjerite je li hotspot uključen.
2. On your device (smartphone, tablet, laptop), open the Wi-Fi settings.
3. Traži available Wi-Fi networks. The hotspot's network name (SSID) will typically be printed on a label inside the device or on the packaging.
4. Select the hotspot's SSID and enter the Wi-Fi password (also found on the label).
5. Once connected, your device will have internet access via the hotspot.

5.3. Using as a Power Bank

1. Connect your external device (e.g., smartphone) to the hotspot's Type-C connector using a compatible charging cable.
2. The hotspot will begin charging your device. The battery indicator lights will show the remaining power.

Figure 4: The Cuifati hotspot being used to charge a smartphone, illustrating its power bank capability.

Figure 5: Illustration of the hotspot supporting multiple connected devices, including laptops and smartphones.

6. Održavanje

• Keep the device dry. Do not expose it to moisture or liquids.
• Uređaj čistite mekom, suhom krpom. Ne koristite jake hemikalije ili abrazivna sredstva za čišćenje.
• Izbjegavajte ekstremne temperature. Uređaj čuvajte na hladnom i suhom mjestu.
• Ne pokušavajte sami rastavljati ili popravljati uređaj. To će poništiti garanciju.

7. Otkrivanje problema

7.1. Nema internetske veze

• Provjerite SIM karticu: Provjerite je li SIM kartica ispravno umetnuta i aktivirana s podatkovnim planom.
• Jačina signala: Verify the signal indicator lights. If signal is weak or absent, move to an area with better network coverage.
• Veza uređaja: Confirm your device is properly connected to the hotspot's Wi-Fi network.
• Ponovno pokretanje: Isključite hotspot, pričekajte nekoliko sekundi, a zatim ga ponovo uključite.

7.2. Hotspot Not Powering On

• Nivo baterije: Ensure the device is sufficiently charged. Connect it to a power source and try again.
• Charging Cable/Adapter: Try a different USB cable or power adapter to rule out faulty accessories.

7.3. Spora brzina veze

• Zagušenje mreže: High network traffic in your area can affect speeds.
• Broj uređaja: Too many devices connected simultaneously can reduce individual speeds.
• Jačina signala: A weak 5G/4G signal will result in slower speeds.

7.4. Power Bank Function Not Working

• Hotspot Battery: Ensure the hotspot has sufficient battery charge to power another device.
• Kablovska veza: Verify the charging cable between the hotspot and the external device is securely connected and functional.

8. Tehničke specifikacije

9. Garancija i podrška

For warranty information and technical support, please refer to the documentation provided with your purchase or contact Cuifati customer service. Keep your proof of purchase for warranty claims.

For further assistance, you may visit the Cuifati store on Amazon: Cuifati Store
