1. Važne informacije o sigurnosti
Please read all instructions carefully before using the One Touch KC12 Electric Jar Opener. Retain this manual for future reference.
- Ovaj uređaj je namijenjen samo za upotrebu u domaćinstvu.
- Ne uranjajte jedinicu u vodu ili bilo koju drugu tečnost.
- Keep hands and loose clothing clear of moving parts during operation.
- Do not attempt to open jars that are too large or too small for the device's grip mechanism.
- Provjerite da li su baterije pravilno umetnute prema oznakama polariteta.
- Uklonite baterije ako se uređaj neće koristiti duži period.
- Čuvati van domašaja djece.
- Do not force the opener. If it struggles, check the jar size or battery level.
2. Sadržaj paketa
- One Touch KC12 Electric Jar Opener
- Uputstvo za upotrebu
Figure 1: The One Touch KC12 Electric Jar Opener, shown from a front-side angle.
3. Proizvod je gotovview
The One Touch KC12 is an automatic jar opener designed for ease of use. It features a compact design with a single activation button.
- Glavna jedinica: Sadrži odjeljak za motor i bateriju.
- Activation Button: Green button on top to start and stop the operation.
- Grip Arms: Adjustable arms that secure the opener to the jar lid and body.
- Mehanizam za rezanje: Internal mechanism that twists the jar lid.
Slika 2: Ugaoni view of the jar opener, highlighting its compact design and grip arms.
4. Podešavanje
4.1 Instalacija baterije
The One Touch KC12 requires two (2) AA batteries (not included) for operation.
- Turn the jar opener upside down to locate the battery compartment.
- Otvorite poklopac odeljka za baterije.
- Umetnite dvije AA baterije, pazeći na ispravan polaritet (+/-) kao što je naznačeno unutar odjeljka.
- Čvrsto zatvorite poklopac odeljka za baterije.
Slika 3: Dno view of the jar opener, illustrating the battery compartment location.
5. Uputstvo za upotrebu
Follow these steps to open a jar using your One Touch KC12 Electric Jar Opener:
- Place the jar on a flat, stable surface.
- Position the jar opener on top of the jar lid. Ensure the grip arms are centered over the lid and the main unit is stable on the jar.
- Press the green activation button once. The opener will automatically adjust its grip to the jar lid and body.
- The opener will then rotate the lid counter-clockwise until it is loosened. The process is fully automatic and hands-free.
- Once the lid is loosened, the opener will stop. Carefully lift the opener off the jar.
- Remove the loosened lid by hand.
Napomena: The opener is designed to work with most standard jar sizes. If the opener struggles or stops prematurely, ensure the jar is placed correctly and the batteries have sufficient power.
Figure 4: A hand pressing the green activation button on the jar opener, which is positioned on a jar.
Figure 5: The jar opener in action, gripping and rotating a jar lid.
6. Održavanje i njega
Proper care will ensure the longevity of your One Touch KC12 Electric Jar Opener.
- čišćenje: Obrišite vanjski dio jedinice s oglasomamp krpom. Ne koristite abrazivna sredstva za čišćenje niti uranjajte uređaj u vodu.
- Skladištenje: Store the opener in a dry place away from direct sunlight and extreme temperatures.
- Zamjena baterije: Replace batteries when the opener's performance diminishes or if it fails to operate.
7. Otkrivanje problema
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Opener does not start. | Prazne ili nepravilno umetnute baterije. | Provjerite polaritet baterija. Zamijenite novim AA baterijama. |
| Opener struggles or stops mid-operation. | Low battery power; jar lid is too tight; jar size is incompatible. | Replace batteries. Ensure the opener is correctly positioned. Verify jar size is within the opener's capacity. |
| Jar lid is not fully loosened. | Opener stopped prematurely; extremely tight seal. | Reposition the opener and try again. If still difficult, the lid may require additional manual effort after the opener has weakened the seal. |
8. Specifikacije
- Brand: One Touch
- Broj modela: KC12
- Boja: Bijelo
- Materijal: Plastika
- Težina artikla: 155 grama
- Način rada: Automatski
- Izvor napajanja: 2 x AA baterije (nisu uključene)
- Materijal oštrice: nerđajući čelik
9. Informacije o garanciji
Warranty information for the One Touch KC12 Electric Jar Opener is not explicitly provided in the product details. Please refer to your purchase receipt or contact the retailer for specific warranty terms and conditions.
10. Korisnička podrška
For further assistance or inquiries regarding your One Touch KC12 Electric Jar Opener, please contact the retailer or manufacturer directly. Specific contact details are not provided in the product information.
