One For All WM5620 Premium Tilt TV Wall Mount Instruction Manual

Uvod

This manual provides comprehensive instructions for the safe and correct installation, operation, and maintenance of your One For All WM5620 Premium Tilt TV Wall Mount. Please read this manual thoroughly before beginning installation and retain it for future reference. Proper installation is crucial for the safety and stability of your television.

Slika: Front view of the One For All WM5620 Premium Tilt TV Wall Mount, showing the wall plate and TV brackets.

Važne informacije o sigurnosti

• Pročitajte sva uputstva: Before installation, carefully read and understand all instructions. If you have any questions, contact customer support.
• Kapacitet težine: Do not exceed the maximum weight capacity of 176 lbs (80 kg). This mount is designed for TVs between 42 inches and 100 inches.
• Struktura zida: Ensure the wall structure can safely support the combined weight of the mount and the television. Consult a qualified professional if unsure.
• Alati: Use appropriate tools for installation. Wear safety glasses and other protective gear as needed.
• djeca: Držite djecu podalje od područja instalacije.
• UL na listi: Ovaj proizvod je UL certificiran, što ukazuje na usklađenost sa sigurnosnim standardima.

Image: The UL Listed certification logo, indicating product safety compliance.

Sadržaj paketa

Verify that all components are present and undamaged before proceeding with installation. If any parts are missing or damaged, do not attempt to install the mount. Contact customer support for assistance.

• Sklapanje zidne ploče
• TV nosači (2)
• Hardware Kit (various screws, washers, spacers, wall anchors)
• Spirit Level
• Uputstvo za upotrebu

Image: Product packaging for the One For All WM5620, illustrating the mount and key features.

Specifikacije

VESA kompatibilan

176 lbs. Capacity

Tilt Up to 15°

Uputstva za instalaciju

Before you begin, ensure you have all necessary tools and have read the safety information. For detailed visual guidance, consider using the One For All Assistant app.

1. Provjere prije instalacije

• Determine TV Weight and Size: Confirm your TV's weight is within 176 lbs and screen size is between 42" and 100".
• Provjerite VESA uzorak: Locate the mounting holes on the back of your TV and measure the horizontal and vertical distance (in mm) to determine the VESA pattern. Ensure it falls within 100x100 to 600x400 mm.
• Identifikujte vrstu zida: This mount is designed for wood stud walls (up to 24-inch on-center studs) or solid concrete/brick walls. Do not install on drywall alone.
• Skupite alate: You will need a drill, stud finder, level (one is included), measuring tape, pencil, and appropriate drill bits.

2. Mounting the Wall Plate

1. Označite poziciju: Determine the desired height for your TV. Hold the wall plate against the wall and use the included spirit level to ensure it is perfectly horizontal. Mark the drill holes with a pencil.
2. Izbušite pilot rupe:
   • For wood studs: Drill pilot holes into the center of the studs at the marked locations.
   • For concrete/brick: Drill pilot holes and insert the appropriate wall anchors (included in hardware kit).
3. Sigurna zidna ploča: Attach the wall plate to the wall using the provided lag bolts and washers. Tighten securely, but do not overtighten.

Image: The wall plate component of the TV mount, ready for installation.

3. Attaching TV Brackets

1. Select Screws: Choose the correct diameter and length of screws from the hardware kit that fit your TV's VESA mounting holes. Use washers and spacers if necessary to ensure a snug fit without overtightening.
2. Pričvrstite zagrade: Securely attach the two TV brackets to the back of your television. Ensure they are oriented correctly (usually with the hooks facing downwards) and are evenly spaced. The anti-scratch padding on the brackets protects your TV.

Slika: Krupni plan view of a TV bracket, showing the mounting holes and design.

4. Mounting TV to Wall Plate

1. Hook TV: With assistance, carefully lift the television and hook the TV brackets onto the top edge of the wall plate.
2. Sigurna televizija: Gently lower the TV until the brackets fully engage with the wall plate. The easy lock-and-release feature will secure the TV in place. Pull the release cords to ensure the TV is properly seated and locked.
3. Adjust Centering: The mount features an adjustable centering system, allowing you to slide the TV horizontally on the wall plate for optimal positioning after it's mounted.

Uputstvo za upotrebu

Adjusting TV Tilt

The One For All WM5620 mount allows for a tilt adjustment of up to 15 degrees. This feature helps reduce glare and optimize viewing angles.

1. Unlock Tilt (if applicable): Some tilt mechanisms may have a locking knob or lever. Loosen these if present.
2. Podesite ugao: Gently push the top or bottom of the TV to achieve the desired tilt angle. The mount is designed to hold the angle once set.
3. Lock Tilt (if applicable): If your mount has a locking mechanism, tighten it to secure the TV at the chosen tilt angle.

Slika: Sa strane view of a television mounted on the wall, demonstrating the tilt capability.

Slika: Detaljna view of the tilt mechanism on the TV wall mount bracket.

Removing the TV from the Mount

To remove the TV, pull the easy lock-and-release cords located at the bottom of the TV brackets. This will disengage the locking mechanism, allowing you to lift the TV off the wall plate. Always have assistance when removing the TV.

Održavanje

• Redovni pregled: Povremeno provjeravajte sve vijke i spojeve kako biste bili sigurni da su čvrsto zategnuti i sigurni.
• čišćenje: Očistite nosač mekom, suhom krpom. Izbjegavajte abrazivna sredstva za čišćenje ili rastvarače koji bi mogli oštetiti završnu obradu.
• Provjera oštećenja: If any part of the mount appears damaged or worn, discontinue use and contact customer support for replacement parts or advice.

Rješavanje problema

Garancija i podrška

The One For All WM5620 Premium Tilt TV Wall Mount comes with a 10 godine garancije, što pokriva nedostatke u materijalu i izradi pri normalnoj upotrebi. Molimo sačuvajte dokaz o kupovini za reklamacije u slučaju garancije.

For further assistance, troubleshooting, or to access detailed installation guides, please refer to the Jedan za sve Podrška Website ili preuzmite One For All Assistant app, available on major app stores. The app provides interactive installation help and product information.

Image: A mounted television with a "10 Year Guarantee" emblem, highlighting the product's warranty.
