UPBRIGHT 12V AC/DC Adapter User Manual

1. Proizvod je gotovview

This UPBRIGHT 12V AC/DC Adapter is designed to provide reliable power to compatible Echelon Connect Spin Exercise Fitness Bikes. It is a genuine, UL Listed power supply ensuring safety and performance.

Ključne karakteristike:

• Ulazni voltage: World Wide Input Voltage 100-240VAC 50/60Hz.
• Izlaz: 12V DC, 5A, 60W.
• Sigurnosne zaštite: OVP (Preko Voltage Output Protection), OCP (Over Current Output Protection), SCP (Short Circuit Output Protection).
• Certifikacija: UL Listed.

Important Compatibility Note: This adapter is NOT for Echelon "Connect Sport" Bike (ECH-SPORT). Please verify your Echelon Connect model number for compatibility before use.

Image 1.1: The UPBRIGHT AC/DC Adapter displayed alongside Echelon Connect spin bikes, illustrating its intended use and compatibility. The image also shows the adapter's packaging.

2. Sigurnosne informacije

Molimo vas da pročitate i razumjete sva sigurnosna uputstva prije upotrebe ovog proizvoda. Nepoštivanje ovih uputstava može dovesti do strujnog udara, požara ili drugih opasnosti.

• Use only in dry locations. Do not expose the adapter to water, rain, or excessive moisture.
• Do not cover the adapter with cloth, paper, or any other material during operation. Ensure adequate ventilation to prevent overheating.
• Be cautious as the surface of the adapter may become warm during prolonged use. This is normal, but avoid direct contact for extended periods.
• Do not attempt to open, modify, or repair the adapter. Refer all servicing to qualified personnel.
• Čuvati van domašaja djece.
• Ensure the power outlet is easily accessible and unplug the adapter when not in use for extended periods.

Image 2.1: The adapter's label detailing electrical specifications (Input: 100-240V~, 50/60Hz, 2.0A; Output: 12V=, 6.2A) and safety symbols, including UL listing and warnings against covering the unit.

3. Sadržaj paketa

Nakon otvaranja paketa, trebali biste pronaći sljedeći artikal:

• 1 x UPBRIGHT 12V AC/DC Adapter
• 1 x Suitable AC Power Cord (specific to your country/region)

Image 3.1: An illustration of different regional AC power cords (US, EU, UK, AU) that are supplied with the adapter to ensure compatibility in various countries. A warranty certificate is also depicted.

4. Upute za postavljanje

Follow these steps to properly connect your UPBRIGHT AC/DC Adapter to your Echelon Connect Spin Bike:

1. Raspakujte adapter: Carefully remove the adapter and its power cord from the packaging.
2. Identify the DC Input Port: Locate the DC power input port on your Echelon Connect Spin Bike. This is typically a circular port.
3. Connect the DC Barrel Connector: Take the barrel connector end of the UPBRIGHT adapter cable and firmly insert it into the DC input port of your spin bike. Ensure it is fully seated.


Slika 4.1: Detaljan view of the barrel connector, which is the output plug of the adapter designed to connect to the Echelon bike's power input.

4. Povežite kabl za napajanje naizmeničnom strujom: Plug the appropriate AC power cord (provided) into the adapter's input socket.
5. Priključite na zidnu utičnicu: Insert the other end of the AC power cord into a standard wall power outlet (100-240VAC).
6. Provjerite snagu: Once connected, your Echelon Connect Spin Bike should receive power. Look for any indicator lights on the bike or adapter to confirm.

5. Uputstvo za upotrebu

The UPBRIGHT AC/DC Adapter functions as a direct power supply for your Echelon Connect Spin Bike. There are no specific operational controls on the adapter itself.

1. Uključeno: After connecting the adapter as described in the Setup section, your Echelon Connect Spin Bike should automatically power on or be ready to be powered on via its own controls.
2. Normalna upotreba: Use your Echelon Connect Spin Bike as per its own user manual. The adapter will continuously supply power during operation.
3. Iskljuciti: To power off your spin bike, follow the instructions in your bike's user manual. To completely disconnect power from the adapter, unplug it from the wall outlet.

6. Održavanje

Proper care and maintenance will extend the life of your UPBRIGHT AC/DC Adapter:

• čišćenje: Disconnect the adapter from the power outlet and the bike before cleaning. Use a soft, dry cloth to wipe the exterior. Do not use liquid cleaners or aerosols.
• Skladištenje: When not in use, store the adapter in a cool, dry place, away from direct sunlight and extreme temperatures. Avoid tightly winding the cables to prevent damage.
• inspekcija: Periodically inspect the adapter and cables for any signs of damage, such as frayed wires, cracked casing, or bent pins. If damage is found, discontinue use and replace the adapter.

7. Otkrivanje problema

If you encounter issues with your UPBRIGHT AC/DC Adapter, refer to the following common troubleshooting steps:

• No Power to Bike:
  • Ensure the adapter's barrel connector is fully inserted into the bike's DC input port.
  • Verify that the AC power cord is securely connected to both the adapter and the wall outlet.
  • Testirajte zidnu utičnicu s drugim uređajem kako biste potvrdili da je funkcionalna.
  • Check for any visible damage to the adapter or cables. If damaged, do not use.
• Adapter se zagrijava na dodir:
  • It is normal for the adapter to feel warm during operation.
  • Ensure the adapter is not covered and has adequate ventilation. Excessive heat could indicate a problem or insufficient airflow.
• Bike Powers On Intermittently:
  • Provjerite sve spojeve na labavost.
  • Ensure the adapter specifications (12V, 5A) match the requirements of your Echelon Connect bike.

If these steps do not resolve the issue, please contact UPBRIGHT customer support or your retailer for further assistance.

8. Specifikacije

9. Garancija i podrška

UPBRIGHT stands behind the quality of its products. This adapter comes with the following warranty and support:

• Politika povrata novca: Povrat novca u roku od 30 dana.
• Politika razmjene: Zamjena na 24 mjeseca.
• A Limited Warranty Certificate is included with your product. Please refer to this document for full terms and conditions.

For warranty claims, technical support, or any questions regarding your UPBRIGHT AC/DC Adapter, please contact the seller or UPBRIGHT customer service directly. Contact information can typically be found on the product packaging or the retailer's website.
