Cecotec ForceClima 7450 Touch Connected Portable Air Conditioner User Manual

1. Uvod

Thank you for choosing the Cecotec ForceClima 7450 Touch Connected Portable Air Conditioner. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new appliance. Please read it thoroughly before use and keep it for future reference.

Figure 1.1: Cecotec ForceClima 7450 Touch Connected Portable Air Conditioner

The ForceClima 7450 Touch Connected is designed to provide effective cooling, ventilation, and dehumidification for spaces up to 15 m². It features a powerful 7000 BTU cooling capacity, a user-friendly touch control panel, a remote control, and Wi-Fi connectivity for convenient operation via your smartphone.

2. Sigurnosna uputstva

Da biste smanjili rizik od požara, strujnog udara ili ozljeda prilikom korištenja klima uređaja, slijedite ove osnovne mjere opreza:

• Always connect the unit to a grounded power outlet with the correct voltage (230 volti).
• Ne koristite klima uređaj s oštećenim kabelom ili utikačem.
• Osigurajte odgovarajuću ventilaciju oko uređaja. Ne blokirajte ulaze ili izlaze zraka.
• Ne stavljajte prste ili strane predmete u otvore za ulaz/izlaz zraka.
• Keep the unit away from water and other liquids. Do not use it in bathrooms or very humid environments.
• Isključite uređaj iz struje prije čišćenja ili bilo kakvog održavanja.
• Do not attempt to repair or modify the unit yourself. Contact qualified service personnel for repairs.
• Ensure the exhaust hose is properly installed to expel hot air outside.
• Nadgledajte djecu kako biste bili sigurni da se ne igraju s uređajem.

3. Sadržaj paketa

Carefully unpack your air conditioner and check that all items are present and in good condition:

• Cecotec ForceClima 7450 Touch Connected Portable Air Conditioner Unit
• Daljinski upravljač
• Ispušno crijevo
• Komplet za zaptivanje prozora
• Drenažno crijevo
• Uputstvo za upotrebu

4. Značajke proizvoda

The Cecotec ForceClima 7450 Touch Connected offers a range of features for optimal comfort:

• Kapacitet hlađenja: 7000 BTU, suitable for rooms up to 15 m².
• Snaga: 790 vati.
• Opcije kontrole: Intuitive touch control panel, remote control, and Wi-Fi connectivity via smartphone app.
• Prikaz: Clear LED screen showing current settings.
• Načini rada:
  1. Način hlađenja: For effective temperature reduction.
  2. Način rada ventilatora: Cirkuliše vazduh bez hlađenja.
  3. Način odvlaživanja: Removes up to 20 liters of moisture per day, improving air quality.
  4. Noćni način rada: Operates quietly for undisturbed sleep.
• Brzine ventilatora: Two adjustable speeds (Low and High).
• Funkcija tajmera: Programmable for up to 24 hours.
• prenosivost: Opremljen kotačima za lakše kretanje.

5. Podešavanje

Slijedite ove korake za postavljanje vašeg prijenosnog klima uređaja:

5.1 Pozicioniranje jedinice

Place the air conditioner on a flat, stable surface, ensuring there is at least 30 cm of clear space around the unit for proper airflow. Position it near a window or opening for exhaust hose installation.

5.2 Installing the Exhaust Hose

1. Pričvrstite jedan kraj ispušnog crijeva na otvor za zrak na stražnjoj strani uređaja.
2. Produžite ispušno crijevo i pričvrstite adapter za prozor na drugi kraj.
3. Open the window and install the window sealing kit. Secure the window adapter into the opening of the sealing kit to ensure hot air is expelled outside and warm air does not re-enter the room.

Figure 5.1: Proper installation of the exhaust hose in a window

5.3 Priključak za napajanje

Plug the power cord into a standard 230V grounded electrical outlet. Ensure the outlet is suitable for the appliance's power requirements.

6. Uputstvo za upotrebu

Your Cecotec ForceClima 7450 Touch Connected can be operated using the touch control panel, the remote control, or the dedicated smartphone app.

6.1 Rad na kontrolnoj tabli

Slika 6.1: Kontrolna ploča osjetljiva na dodir

Figure 6.2: Interacting with the Control Panel

• Dugme za napajanje: Pritisnite da uključite ili isključite jedinicu.
• Dugme za način rada: Cycle through Cooling, Fan, Dehumidification, and Night modes. The selected mode will be indicated on the LED display.
• Dugmad za podešavanje temperature (gore/dolje): Adjust the desired temperature in Cooling mode.
• Dugme za brzinu ventilatora: Toggle between Low and High fan speeds.
• Dugme za tajmer: Podesite tajmer za automatsko isključivanje (do 24 sata).

6.2 Rad na daljinskom upravljaču

The remote control allows you to operate all functions of the air conditioner from a distance. Ensure there are no obstructions between the remote control and the unit's receiver.

• Dugmad na daljinskom upravljaču odgovaraju funkcijama na kontrolnoj tabli.
• Insert 2x AAA batteries (not included) into the remote control before first use.

6.3 Wi-Fi kontrola (aplikacija za pametne telefone)

The Cecotec ForceClima 7450 Touch Connected can be controlled remotely via a smartphone app. This allows you to manage settings from anywhere with an internet connection.

Figure 6.3: Controlling the unit via the Cecotec App

1. Download the official Cecotec app from your smartphone's app store (iOS or Android).
2. Registrujte račun ili se prijavite.
3. Follow the in-app instructions to add your ForceClima 7450 Touch Connected unit. This typically involves putting the unit into pairing mode and connecting it to your home Wi-Fi network.
4. Once connected, you can control all functions, including power, mode, temperature, fan speed, and timer, directly from your smartphone.

7. Održavanje

Redovno održavanje osigurava optimalne performanse i produžava vijek trajanja vašeg klima uređaja.

7.1 Čišćenje vazdušnog filtera

Zračni filter treba čistiti svake dvije sedmice ili češće, ovisno o upotrebi i kvaliteti zraka. Zaprljan filter može smanjiti efikasnost hlađenja i protok zraka.

1. Isključite klima uređaj iz električne utičnice.
2. Locate and remove the air filter from the back or side of the unit (refer to the diagram in your quick start guide if unsure).
3. Clean the filter using a vacuum cleaner to remove dust. For stubborn dirt, wash it gently with lukewarm water and a mild detergent.
4. Allow the filter to dry completely before reinserting it into the unit. Do not expose it to direct sunlight.

7.2 Ispuštanje nakupljene vode

During cooling and dehumidification, water will accumulate inside the unit. The unit has an internal water tank, but for continuous operation or high humidity, manual drainage may be required.

• When the internal tank is full, the unit may stop operating and display an indicator.
• Isključite jedinicu.
• Place a shallow pan or bucket under the drainage outlet at the bottom rear of the unit.
• Uklonite čep za odvod i pustite da sva voda iscuri.
• For continuous drainage, attach the provided drainage hose to the outlet and direct it to a floor drain or suitable container.
• Replace the drain plug securely after draining.

7.3 Čišćenje vanjskog dijela uređaja

Obrišite spoljašnjost jedinice mekom krpom, damp krpom. Ne koristite jake hemikalije, abrazivna sredstva za čišćenje ili rastvarače, jer mogu oštetiti površinu.

8. Otkrivanje problema

Prije nego što kontaktirate korisničku službu, molimo pogledajte sljedeće uobičajene probleme i rješenja:

9. Specifikacije

10. Garancija i podrška

Cecotec products are manufactured to high-quality standards. This product is covered by a manufacturer's warranty against defects in materials and workmanship from the date of purchase. Please retain your proof of purchase for warranty claims.

For technical support, spare parts, or warranty service, please contact Cecotec customer service through their official website or the contact information provided in your product's packaging. Do not attempt to repair the unit yourself, as this may void the warranty.
