1. Sigurnosne informacije
WARNING: This is not a toy. Misuse may cause serious injury or death. Always treat this air pistol with the same respect as a firearm. Read and understand all instructions before use.
- Always wear appropriate eye protection when handling or operating this air pistol.
- Keep fingers off the trigger until ready to fire.
- Never point the air pistol at anything you do not intend to shoot.
- Ensure the area behind your target is clear and safe.
- Store the air pistol unloaded and uncharged in a secure location, out of reach of children and unauthorized users.
- Do not modify the air pistol. Any modifications may compromise safety and performance.
- Use only .50 caliber powder balls or rubber balls designed for this air pistol. Do not use unauthorized projectiles.
- CO2 cartridges can be dangerous if mishandled. Follow all instructions for CO2 installation and removal.
2. Proizvod je gotovview
The Umarex P2P HDP .50 Caliber Powder Ball Air Pistol is designed for training and practice with .50 caliber powder balls or rubber balls. It features a CO2 activation system for quick readiness.
Slika 2.1: Prednja strana view of the Umarex P2P HDP .50 Caliber Powder Ball Air Pistol.
Figure 2.2: The air pistol shown with .50 caliber powder balls, rubber balls, and 12g CO2 cartridges (not included).
Ključne karakteristike:
- Shoots .50 caliber powder balls or rubber balls.
- Easy loading mechanism.
- Integrated trigger safety.
- CO2 activation system for immediate readiness.
3. Podešavanje i učitavanje
3.1 Installing the CO2 Cartridge
- Ensure the air pistol is unloaded and pointed in a safe direction.
- Unscrew the CO2 cap at the bottom of the grip.
- Insert one 12g CO2 cartridge into the grip with the narrow end facing up.
- Screw the CO2 cap back on. Tighten it until snug, but avoid overtightening, as this can damage the seal or prevent CO2 flow. The CO2 cartridge is now housed but not activated.
Figure 3.1: The CO2 cap detached from the pistol grip.
Figure 3.2: A 12g CO2 cartridge being placed into the pistol's grip.
3.2 Loading Projectiles
- Ensure the air pistol is pointed in a safe direction.
- Pull the follower back from the front of the barrel.
- Insert up to six .50 caliber powder balls or rubber balls into the loading chamber.
- Slowly release the follower back into position. The air pistol is now loaded.
Figure 3.3: The loading chamber of the air pistol in the open position.
Slika 3.4: Detaljan view of the internal loading mechanism.
4. Uputstvo za upotrebu
4.1 Activating CO2
To activate the CO2 cartridge, firmly tap the bottom of the CO2 cap against a hard surface. This punctures the cartridge, making the air pistol ready to fire. Only activate the CO2 when you intend to use the air pistol immediately.
4.2 Firing the Air Pistol
- Ensure the CO2 is activated and the air pistol is loaded.
- Aim at a safe and appropriate target.
- Pull the trigger. The trigger safety is disengaged as the trigger is pulled.
- After firing, if more shots are desired, ensure the air pistol remains pointed in a safe direction and continue to fire until empty or until the CO2 pressure is depleted.
5. Održavanje
Regular maintenance ensures the longevity and reliable operation of your Umarex P2P HDP air pistol.
- čišćenje: Povremeno čistite vanjski dio zračnog pištolja mekom,amp tkanina. Izbjegavajte korištenje jakih kemikalija ili abrazivnih materijala.
- Barrel Cleaning: If projectiles become stuck or accuracy decreases, use a cleaning rod or the provided tool to gently clear the barrel.
- CO2 Seal Care: Apply a drop of silicone oil to the tip of new CO2 cartridges before insertion to help maintain the integrity of the internal seals.
- Skladištenje: Always store the air pistol unloaded and with the CO2 cartridge removed (and depleted if activated). Store in a cool, dry place away from direct sunlight and extreme temperatures.
Figure 5.1: The loading tool, which can also be used for clearing stuck projectiles.
6. Otkrivanje problema
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Air pistol does not fire or fires weakly. | CO2 cartridge not activated or empty. CO2 cap overtightened. | Ensure CO2 cartridge is new and activated. Do not overtighten the CO2 cap; tighten until snug. Replace empty cartridge. |
| Projectile stuck in the barrel. | Deformed projectile or improper loading. | Use the provided loading tool or a cleaning rod to gently push the projectile out from the muzzle end. Ensure only recommended .50 caliber projectiles are used. |
| CO2 cap difficult to remove after activation. | Pressure build-up from activated CO2. | Ensure all gas is depleted by firing the air pistol until no more pressure is felt. If still stuck, seek professional assistance. Avoid overtightening the cap during installation. |
| Inconsistent accuracy. | Dirty barrel, inconsistent projectiles, or low CO2 pressure. | Clean the barrel. Use high-quality, consistent .50 caliber projectiles. Replace CO2 cartridge if pressure is low. |
7. Specifikacije
| Feature | Detalj |
|---|---|
| Brand | Umarex |
| Naziv modela | P2P HDP .50 Caliber Air Pistol |
| Kalibar | .50 kalibar |
| Izvor napajanja | 12g CO2 Cartridge |
| Kapacitet | 6 rundi |
| Materijal bačve | legirani čelik |
| Materijal okvira | Polimer |
| Težina artikla | 2.25 funti |
| Dimenzije proizvoda (DxŠxV) | 2.5" x 10" x 10.25" |
| UPC | 723364923050 |
| Broj dijela | 2292305 |
8. Garancija i podrška
For warranty information, technical support, or to purchase accessories and replacement parts, please visit the official Umarex website or contact Umarex customer service. Keep your purchase receipt for warranty claims.
Više informacija i kontakt podatke možete pronaći na Umarex trgovina na Amazonu.
