Uvod
This manual provides essential information for the safe and effective installation, operation, and maintenance of your Alfanar 13 Amp 250 Volt switch socket. Designed for reliability and safety, this product features a comfortable design with a secure grip system, safe stop protection, and overload protection. Its high conductivity is ensured by high-quality copper construction, making it ideal for both home and workplace environments. Please read this manual thoroughly before use.
Ključne karakteristike:
- Comfortable design with safety and grip system.
- Safe stop protection, providing overload protection.
- High conductivity due to high-quality copper construction.
- Ideal for use in home or workplace.
- Izrađen od visokokvalitetnih materijala za dugotrajnu izdržljivost.
Sigurnosne informacije
Always ensure power is disconnected before installation or maintenance. This product should be installed by a qualified electrician in accordance with local wiring regulations. Do not exceed the rated current and voltage. Keep out of reach of children. Do not use if the product appears damaged.
Sadržaj paketa
- Alfanar New 13 Amp 250 Volt DP SWT SCK 7X7 (Model AN12)
- Installation Screws (if applicable)
- Uputstvo za upotrebu
Postavljanje i instalacija
Važno: Installation must be performed by a qualified professional. Ensure the main power supply is switched off at the consumer unit/fuse box before commencing any electrical work.
- Pripremite prostor za instalaciju: Ensure the wall box is correctly sized and securely mounted.
- Ožičenje: Connect the live (brown/red), neutral (blue/black), and earth (green/yellow) wires to the corresponding terminals on the back of the socket. Ensure all connections are tight and secure.
- Montaža: Carefully position the socket into the wall box, ensuring no wires are pinched. Secure the socket to the wall box using the provided screws.
- Pričvrstite prednju ploču: Attach the decorative faceplate (if separate) to the main unit.
- Vrati snagu: Once installation is complete and all connections are checked, restore power at the consumer unit/fuse box.
Slika 1: Prednja strana view of the Alfanar 13 Amp 250V Plug with Switch, showing the socket outlets and the integrated switch.
Slika 2: Bočna strana view of the Alfanar 13 Amp 250V Plug with Switch, highlighting its profile i dizajn.
Uputstvo za upotrebu
The Alfanar 13 Amp 250V Plug with Switch is designed for straightforward operation.
- Povezivanje uređaja: Insert the plug of your appliance into the socket outlets.
- Uključivanje/isključivanje: Use the integrated switch to control the power supply to the connected appliance. Press the switch to the 'ON' position to supply power, and to the 'OFF' position to cut power.
- Zaštita od preopterećenja: The socket is equipped with overload protection. In case of an overload, the power supply may automatically cut off to prevent damage. Disconnect the appliance and check for faults before resetting.
Video 1: Overview of the Alfanar 13 Amp 250V Plug with Switch, demonstrating its features and design. This video is provided by the seller.
Video 2: A product summary video for the Alfanar 13 Amp 250V Plug with Switch, highlighting its key benefits. This video is provided by the seller.
Održavanje
- čišćenje: Disconnect power before cleaning. Wipe the surface with a soft, dry cloth. Do not use abrasive cleaners or solvents.
- Redovne provjere: Periodically inspect the socket for any signs of damage, loose connections, or discoloration. If any issues are found, discontinue use and consult a qualified electrician.
- Zamjena osigurača: If the socket stops working, the fuse might need replacement. Ensure the replacement fuse is of the correct rating (13 Amp). Always disconnect power before attempting to replace the fuse.
Rješavanje problema
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Nema struje iz utičnice. | Main power supply off, tripped circuit breaker, blown fuse, loose wiring. | Check main power supply. Reset circuit breaker. Replace fuse (ensure correct rating). Consult an electrician for wiring issues. |
| Socket feels hot. | Overload, loose connection, faulty appliance. | Disconnect appliance immediately. Reduce load. Check for loose wiring (by electrician). Test appliance on another socket. |
| Switch not working. | Internal fault, damaged switch mechanism. | Discontinue use. Consult a qualified electrician for inspection and replacement. |
Specifikacije
| Feature | Detalj |
|---|---|
| Proizvođač | Alfanar-New Alfanar |
| Broj dijela | AN12 |
| Težina artikla | 200 g |
| Dimenzije proizvoda | 7 x 7 x 4 cm |
| Broj modela | AN12 |
| Boja | Bijelo |
| Stil | 13 Amp Prekidač |
| Materijal | High-quality Copper |
| Oblik | Square |
| Vrsta izvora napajanja | AC |
| Tip prekidača | 2-way |
| Plug Type | Zidni nosač |
| Socket Design | Prekidač |
| Usklađenost | CE |
| Specifične upotrebe | Profesionalno |
| Uključene komponente | Alfanar New 13 Amp 250 Volt DP SWT SCK 7X7 |
| Baterije su potrebne? | br |
| Zemlja porijekla | Kina |
| Način rada | Manual |
| Current Rating | 13 Amp |
| Operating Voltage | 250 volti (AC) |
| Vrsta veze | Normalno otvoren |
| Tip konektora | Utikač |
| Terminal | Screw |
Garancija i podrška
Za informacije o garanciji ili tehničkoj podršci, obratite se službenom servisu proizvođača webweb-mjesto ili kontaktirajte njihovu službu za korisnike. Sačuvajte račun kao dokaz o kupovini.
Proizvođač: Alfanar
Webstranica: Alfanar Store on Amazon.sa
