1. Uvod
The Rowenta IXEO QR1020 All-in-One Iron and Steamer Solution offers a revolutionary garment care experience, combining high-efficiency steaming and lightweight ironing. This versatile device features a built-in three-position Smart Board for ergonomic upright and inclined ironing. With 1500W of power and Turbo Steam Technology, it provides up to 5 bar pump pressure for effective wrinkle removal. The superlight iron head design, rapid 45-second heat-up time, and automatic adjusting temperature feature simplify your daily garment care routine. It also helps sanitize fabrics by killing up to 99.9% of odor-causing bacteria.
2. Sigurnosna uputstva
- Always ensure the appliance is unplugged from the power outlet before filling with water, cleaning, or performing maintenance.
- Ne uranjajte uređaj, kabel za napajanje ili utikač u vodu ili druge tekućine.
- Keep the steam head away from your body and face during operation to avoid steam burns.
- The soleplate of the iron head becomes hot during use. Avoid direct contact with hot surfaces.
- Use only distilled or demineralized water. Tap water may cause mineral buildup and damage the appliance over time.
- Do not use any cleaning agents or chemicals in the water tank.
- Ensure the appliance is placed on a stable, flat surface during use.
- Do not leave the appliance unattended while it is plugged in or operating.
- Čuvati van domašaja djece i kućnih ljubimaca.
3. Podešavanje
3.1 Raspakivanje i identifikacija komponenti
Carefully remove all components from the packaging. Ensure all parts are present before assembly.
3.2 Koraci montaže
- Attach the Steam Pipe: Securely screw the steam pipe into the designated port on the main base unit.
- Insert Adjustable Tubes: Insert the two adjustable telescopic poles into the corresponding holes on the base. Ensure they click into place.
- Assemble Ironing Board: Connect the two parts of the ironing board together.
- Install Ironing Board: Attach the assembled ironing board to the top of the telescopic poles. Adjust the height as desired using the locking mechanisms.
- Attach Steam Head Holder: Secure the steam head holder to one of the telescopic poles at a convenient height.
- Napunite rezervoar za vodu: Remove the 1-liter water tank from the base unit. Fill it with distilled or demineralized water. Reinsert the tank firmly into the base.
4. Uputstvo za upotrebu
4.1 Powering On and Heat-Up
Plug the appliance into a suitable power outlet. Press the power button on the base unit. The steamer will heat up in approximately 45 seconds, indicated by a light or sound (refer to your specific model's indicator). Once ready, the steam head is prepared for use.
4.2 Adjusting the Smart Board
The patented Smart Board offers three positions for optimal garment care:
- Vertikalni položaj: Idealno za peglanje na paru odjevnih predmeta poput haljina, odijela ili zavjesa.
- Horizontalni položaj: Perfect for traditional ironing of shirts, trousers, or linens.
- Položaj pod uglom od 30 stepeni: Provides an ergonomic angle for comfortable ironing and steaming, reducing strain.
To adjust the board, use the release mechanisms located on the back or sides of the board, then tilt or lower it to your desired position until it locks securely.
4.3 Using the Steam Head
The ultra-light steam head is designed for easy maneuverability. Press the steam trigger to release continuous steam. Glide the steam head over your garments, applying gentle pressure if using the ironing function. The heated soleplate and powerful steam work together to remove wrinkles and refresh fabrics.
4.4 Kompatibilnost tkanina
The Rowenta IXEO QR1020 is safe for all fabrics, including delicates. The automatic adjusting temperature feature ensures optimal heating and steaming without the risk of burning or damaging your clothes.
5. Održavanje
5.1 Water Tank Care
Regularly empty and rinse the 1-liter water tank after each use to prevent mineral buildup. Use only distilled or demineralized water to prolong the life of your appliance.
5.2 Anti-Scale System
The appliance is equipped with an anti-scale system to simplify maintenance. Follow the instructions in the full user manual for specific descaling procedures, typically involving rinsing the boiler or using a descaling solution as recommended by the manufacturer.
5.3 Skladištenje
After use, allow the appliance to cool completely. Empty the water tank. The compact design allows for easy storage. Ensure the steam head is securely placed in its holder.
6. Otkrivanje problema
6.1 No Steam Production
- Check if the appliance is properly plugged in and powered on.
- Uverite se da je rezervoar za vodu napunjen vodom.
- Allow sufficient time for the appliance to heat up (approx. 45 seconds).
- Verify that the steam trigger is being pressed correctly.
6.2 Water Leaking from Steam Head
- Ensure the steam head is fully heated before use.
- Avoid tilting the steam head too much, especially when steaming vertically.
- Check for excessive mineral buildup; perform descaling if necessary.
6.3 Appliance Not Heating Up
- Confirm the power cord is securely plugged into a working outlet.
- Check if the power button on the base unit is activated.
- Ako se problem nastavi, kontaktirajte korisničku podršku.
7. Specifikacije
- Brand: Rowenta
- Broj modela: QR1020 (2820102011)
- Boja: Crna
- Wattage: 1500 vati
- Voltage: 110 Volts
- Kapacitet rezervoara za vodu: 1 litar
- Težina artikla: Approximately 1.06 ounces (steam head) / 30 Grams (steam output)
- Prednosti proizvoda: Sanitize
- UPC: 023108102001
8. Garancija i podrška
The Rowenta IXEO QR1020 All-in-One Iron and Steamer Solution is designed for durability and performance. For specific warranty information, including terms and conditions, please refer to the warranty card included with your product or visit the official Rowenta website. For technical support, replacement parts, or service inquiries, please contact Rowenta customer service through their official channels.
