TSL 4 Doors Access Control Controller User Manual

1. Uvod

This manual provides essential information for the proper installation, operation, and maintenance of your TSL 4 Doors Access Control Controller. Please read this manual thoroughly before attempting to install or operate the device to ensure correct usage and to prevent damage.

The TSL 4 Doors Access Control Controller is a robust security solution designed for managing access to up to four doors. It features a high-speed 32-bit processor, supports up to four Wiegand card readers, and can record 10,000 cards and 50,000 event records. Advanced features include anti-passback and authentication password with keypad card reader integration.

2. Sigurnosne informacije

• električna sigurnost: Installation and wiring must be performed by qualified personnel in accordance with all local and national electrical codes. Ensure power is disconnected before making any connections.
• Napajanje: Use only the specified power supply for this device. Incorrect voltage can cause damage or fire.
• Okruženje: Install the controller in a dry, well-ventilated area, away from direct sunlight, extreme temperatures, and high humidity.
• Ožičenje: Refer to the detailed wiring diagram provided inside the enclosure for all connections. Incorrect wiring can lead to malfunction or damage.
• uzemljenje: Ensure the device is properly grounded to prevent electrical shock and ensure stable operation.

3. Proizvod je gotovview

The TSL 4 Doors Access Control Controller is housed in a durable metal enclosure, designed for secure installation. The internal circuit board provides multiple connection points for various access control components.

Figure 1: TSL 4 Doors Access Control Controller with open enclosure. The image shows the green circuit board with various connection terminals and a printed wiring diagram on the inside of the enclosure door.

Ključne karakteristike:

• Controls access for up to 4 doors.
• High-speed 32-bit processor for efficient operation.
• Supports up to 4 Wiegand card readers.
• Capacity for 10,000 user cards and 50,000 event records.
• Anti-passback functionality.
• Authentication password support with keypad card readers.
• Video verification log search with video playback (requires compatible software and cameras).

4. Podešavanje

4.1 Montaža kontrolera

1. Choose a secure, indoor location for mounting the controller, ensuring it is protected from environmental extremes.
2. Use appropriate screws and anchors to securely fasten the metal enclosure to a wall or suitable surface. Ensure the enclosure is level.
3. Allow sufficient space around the enclosure for ventilation and ease of wiring.

4.2 Ožičenje

All wiring should be performed with the power supply disconnected. Refer to the wiring diagram printed inside the controller's enclosure for precise connection points. The following outlines general connection types:

• Napajanje: Connect the appropriate DC power supply to the designated power input terminals. Verify voltage i polaritet.
• Wiegand čitaoci: Connect each Wiegand card reader to its respective door input (D0, D1, LED, BEEP, GND, +12V). Ensure data lines (D0, D1) are correctly matched.
• brave na vratima: Connect electric locks (e.g., magnetic locks, strike locks) to the NO/NC and COM terminals for each door.
• Exit Buttons: Connect exit buttons to the designated 'Exit' input terminals for each door.
• Door Sensors: Connect door contact sensors to the 'Door Sensor' input terminals to monitor door status.
• Mrežna veza: Connect an Ethernet cable to the network port for communication with the management software.

4.3 Početno napajanje

1. Double-check all wiring connections for accuracy and security.
2. Spojite napajanje na električnu utičnicu.
3. Observe the indicator lights on the circuit board. Refer to the product documentation for LED status meanings.
4. Access the controller via the management software for initial configuration, including network settings, time synchronization, and adding administrators.

5. Uputstvo za upotrebu

The TSL 4 Doors Access Control Controller is managed primarily through dedicated access control software (not included with the hardware). This software allows for comprehensive system configuration and user management.

5.1 User and Card Management

• Dodavanje korisnika: Use the software to create new user profiles, assigning unique IDs and access levels.
• Enrolling Cards: Present access cards to a connected reader while in enrollment mode within the software to link them to user profiles.
• Nivoi pristupa: Define specific access permissions for each user, specifying which doors they can access and during what time periods.
• Deleting Users/Cards: Remove access permissions for individuals or lost cards through the software.

5.2 Accessing Doors

• Pristup karticama: Present an enrolled access card to the designated card reader at the door. If access is granted, the door will unlock for a set period.
• Pristup putem tastature: If a keypad reader is used, enter the assigned PIN code followed by presenting the card (if dual authentication is enabled).
• Dugme za izlaz: Press the exit button on the inside of the door to unlock it for egress.

5.3 Event Monitoring and Reporting

The management software provides real-time monitoring of all access events, including successful entries, denied access attempts, and alarms. Event logs can be searched, filtered, and exported for auditing purposes. The system supports video verification log search with video playback when integrated with compatible surveillance systems.

6. Održavanje

• Redovni pregled: Periodically inspect all wiring connections for signs of wear, corrosion, or looseness. Ensure the enclosure is securely closed.
• čišćenje: Keep the controller and its enclosure clean and free of dust. Use a soft, dry cloth. Do not use liquid cleaners or solvents.
• Ažuriranja softvera: Regularly check for and apply firmware updates for the controller and software updates for the management application to ensure optimal performance and security.
• Sigurnosna kopija podataka: Periodically back up your access control database to prevent data loss.

7. Otkrivanje problema

If you encounter issues not listed here or require further assistance, please contact technical support.

8. Specifikacije

9. Informacije o garanciji

Warranty information for the TSL 4 Doors Access Control Controller is not provided in the available product documentation. Please contact your vendor or the manufacturer, LTS, directly for details regarding warranty coverage, terms, and conditions.

10. Podrška

For technical support, troubleshooting assistance, or inquiries regarding your TSL 4 Doors Access Control Controller, please contact the authorized dealer or the manufacturer, LTS. Ensure you have your model number (B07BB88SPZ) and purchase date available when seeking support.
