Einhell TC-SY 400 P Electric Paint Gun Instruction Manual

1. Sigurnosne informacije

Uvijek pročitajte i razumite sva sigurnosna upozorenja, upute, ilustracije i specifikacije koje se isporučuju s ovim električnim alatom. Nepoštivanje svih dolje navedenih uputa može dovesti do strujnog udara, požara i/ili ozbiljnih ozljeda.

• Sigurnost radnog područja: Radno područje održavajte čistim i dobro osvijetljenim. Ne koristite električne alate u eksplozivnim atmosferama, kao što je prisustvo zapaljivih tekućina, plinova ili prašine.
• Lična sigurnost: Always wear appropriate personal protective equipment, including safety glasses, a respirator mask, gloves, and protective clothing. Avoid accidental starting. Ensure the switch is in the off-position before connecting to power, picking up, or carrying the tool.
• električna sigurnost: Utikači električnih alata moraju odgovarati utičnici. Nikada ne modificirajte utikač ni na koji način. Ne izlažite električne alate kiši ili vlazi.
• Hemijska sigurnost: Always refer to the safety data sheet (SDS) for the material being sprayed. Ensure adequate ventilation when spraying paints, lacquers, or stains.
• Djeca i prolaznici: Držite djecu i osobe u blizini dok koristite električni alat. Ometanje može uzrokovati da izgubite kontrolu.

2. Proizvod je gotovview

The Einhell TC-SY 400 P is a lightweight and convenient electric paint spray gun designed for small to medium-sized workspaces. It is suitable for spraying lacquers and glazes, offering precise control for various applications.

2.1 Glavne komponente

• Paint Spray Gun Unit
• Paint Container (800 ml capacity)
• Spray Head (removable)
• Nozzles (2.5 mm black, 2 mm red replacement)
• Viscosity Measuring Cup
• Četka za čišćenje
• Purification Needle for Spray Nozzle
• Storage Lid for Paint Container

Image: The Einhell TC-SY 400 P Electric Paint Gun, a handheld unit with a red and black body and a white paint container attached.

Image: Included accessories: a cleaning brush, a purification needle, two nozzles (black and red), a viscosity measuring cup, and a storage lid for the paint container.

3. Podešavanje

3.1 Preparing the Paint Material

1. Ensure the paint, lacquer, or stain is suitable for spraying. Refer to the material manufacturer's instructions.
2. Use the provided viscosity measuring cup to check the material's viscosity. If too thick, thin the material according to the manufacturer's recommendations.
3. Filter the prepared material to remove any lumps or impurities that could clog the nozzle.

3.2 Assembling the Paint Gun

1. Ensure the paint gun is unplugged from the power supply.
2. Select the appropriate nozzle for your material and desired spray pattern.
3. Attach the spray head to the main unit by twisting it securely.
4. Fill the paint container with the prepared material. Do not overfill.
5. Screw the filled paint container onto the spray head unit until it is firmly attached.

Image: An exploded diagram showing the main components of the Einhell TC-SY 400 P paint gun, including the motor unit, spray head, nozzle, and paint container, illustrating assembly.

4. Uputstvo za upotrebu

4.1 Adjusting Paint Flow

The paint flow can be adjusted to suit the material and desired coverage. Rotate the paint flow regulation knob to increase or decrease the material output.

Image: A graphic illustrating the paint flow regulation mechanism, showing an arrow indicating rotation to adjust the flow from the paint container.

4.2 Podešavanje uzorka prskanja

The air outlet cap can be adjusted to achieve vertical, horizontal, or circular spray patterns. Rotate the air cap to align the desired pattern with the nozzle.

• Vertikalni mlaz: Za horizontalne površine.
• Horizontalni mlaz: Za vertikalne površine.
• Kružni mlaz: For small areas or corners.

Image: A diagram showing three different air cap orientations and their corresponding spray patterns: horizontal, vertical, and circular.

4.3 Tehnika prskanja

1. Hold the paint gun approximately 15-30 cm (6-12 inches) from the surface.
2. Maintain a consistent distance and speed for an even finish.
3. Start spraying off the workpiece and move across, releasing the trigger off the workpiece to avoid overspray and drips.
4. Apply thin, even coats rather than one thick coat. Allow adequate drying time between coats.

Image: A person wearing safety glasses and a mask, using the Einhell TC-SY 400 P paint gun to spray a wooden garden bench outdoors.

5. Održavanje i čišćenje

Proper cleaning after each use is crucial for the longevity and performance of your paint gun.

5.1 Immediate Cleaning

1. Unplug the paint gun from the power supply.
2. Empty any remaining material from the paint container.
3. Fill the container with an appropriate cleaning solution (water for water-based paints, solvent for oil-based paints/lacquers).
4. Spray the cleaning solution through the gun until it runs clear.

5.2 Detailed Cleaning

1. Remove the paint container and spray head.
2. Disassemble the spray head, including the nozzle and air cap.
3. Use the provided cleaning brush and purification needle to thoroughly clean all components that came into contact with the material. Pay special attention to the nozzle and air cap holes.
4. Rinse all parts with clean water or appropriate solvent.
5. Allow all components to dry completely before reassembly or storage.

5.3 Skladištenje

Once clean and dry, reassemble the paint gun. The integrated suspension system allows for easy storage in a minimal space. Store the unit in a dry, dust-free environment, out of reach of children.

6. Otkrivanje problema

Pogledajte donju tabelu za uobičajene probleme i njihova rješenja.

7. Specifikacije

8. Garancija i podrška

Za informacije o garanciji, molimo pogledajte garantni list koji dolazi uz vaš proizvod ili posjetite službenu Einhell stranicu. website. For technical support, spare parts, or service inquiries, please contact Einhell customer service directly. Contact details can typically be found on the manufacturer's weblokaciji ili u originalnoj ambalaži.
