myTouchSmart 33862 Outdoor/Indoor SunSmart 7-Day Plug-in Digital Timer

1. Proizvod je gotovview

The myTouchSmart Plug-in SunSmart™ Outdoor/Indoor Timer is designed to simplify your routine and enhance home security by automating lighting and appliance schedules. This versatile digital timer is compatible with various bulb types, including LED, CFL, incandescent, and halogen, making it suitable for a wide range of applications both indoors and outdoors.

Figure 1: myTouchSmart 33862 Digital Timer. This image displays the timer unit alongside its packaging, highlighting its main features such as custom scheduling, weather resistance, and battery backup for settings.

Ključne karakteristike uključuju:

• Programabilni rasporedi: Set custom ON/OFF times or utilize simple daily presets.
• SunSmart™ Technology: Automatically adjusts ON/OFF times based on local sunrise and sunset.
• Countdown Feature: Customizable countdown from one minute to 24 hours.
• Otporan na vremenske uslove: Durable design suitable for both outdoor and indoor use.
• Rezervna kopija baterije: Zadržava postavke tokom isključivanjatages or when unplugged.
• Dvostruko uzemljene utičnice: Supports multiple plug-in devices.
• LED indikatorska svjetla: Blue LEDs indicate active settings.
• Široka kompatibilnost: Works with LED, CFL, incandescent, and halogen bulbs, including dimmable LED/CFL.

Figure 2: Versatile Application. This image illustrates the timer's suitability for various lighting applications, including landscape, deck and patio, and seasonal decorations.

Figure 3: Bulb Compatibility. This image confirms the timer's compatibility with LED, CFL, Incandescent, and Halogen bulb types.

2. Upute za postavljanje

Follow these steps to set up your myTouchSmart Digital Timer:

1. Uključite tajmer: Insert the timer into a grounded 125V 50/60Hz outlet. For outdoor use, ensure the outlet is GFCI protected and the timer is mounted securely using the built-in options.
2. Postavite trenutno vrijeme:
   • Pritisnite CLOCK button. The display will show the current time setting.
   • Koristite GORE (▲) or DOLJE (▼) buttons to adjust the hour. Press and hold for faster adjustment.
   • Pritisnite SET to move to minute adjustment. Use GORE (▲) or DOLJE (▼) dugmad.
   • Pritisnite SET again to confirm and exit time setting.
3. Početna naplata: Allow the timer to charge for at least 30 minutes before programming to ensure the battery backup is fully functional.

Figure 4: Simple Setup Guide. This image visually guides the user through the initial setup process, including setting the current time and programming ON/OFF schedules.

3. Uputstvo za upotrebu

The myTouchSmart timer offers several programming options to suit your needs:

3.1. Setting Custom ON/OFF Times (My ON/My OFF)

You can program up to 8 custom ON/OFF times for specific days or combinations of days.

1. Pritisnite MY ON TIME button to set an ON time. The display will show "ON" and the current program number.
2. Koristi GORE (▲) or DOLJE (▼) to adjust the hour, then SET premjestiti na minute.
3. Pritisnite SET to select the day(s) of the week for this program. Use GORE (▲) or DOLJE (▼) to cycle through options (e.g., everyday, weekdays, weekends, specific days).
4. Repeat steps 1-3 for the corresponding MY OFF TIME button. Ensure the ON and OFF times are for the same program number.
5. Pritisnite SET da sačuvate program.

3.2. SunSmart™ Programming (Sunset ON/Sunrise OFF)

This feature automatically adjusts to local sunrise and sunset times.

• Pritisnite SUNSET ON button to activate the timer at sunset.
• Pritisnite SUNRISE OFF button to deactivate the timer at sunrise.
• The timer uses your set current time to determine your region's sunrise/sunset.

3.3. Evening Preset

This preset turns the timer ON at sunset and OFF at 12:00 AM.

• Pritisnite EVENING ON - 12AM button to activate this preset.

3.4. Tajmer za odbrojavanje

Set a custom countdown for the timer to turn OFF after a specified duration (1 minute to 24 hours).

• Pritisnite MY EXTRA PROGRAMS button until "CD" (Countdown) appears.
• Koristi GORE (▲) or DOLJE (▼) to set the desired countdown duration.
• Pritisnite SET za početak odbrojavanja.

Figure 5: Programming Options. This image details the different scheduling capabilities of the timer, such as custom ON/OFF times, automatic sunrise/sunset adjustments, and evening presets.

4. Održavanje

To ensure optimal performance and longevity of your myTouchSmart Digital Timer, follow these maintenance guidelines:

• čišćenje: Disconnect the timer from the power outlet before cleaning. Use a soft, dry cloth to wipe the exterior. Do not use harsh chemicals or abrasive cleaners.
• Uslovi okoline: While weather-resistant, avoid submerging the timer in water or exposing it to extreme temperatures beyond its operating range.
• Skladištenje: If storing the timer for an extended period, unplug it and keep it in a cool, dry place.
• Rezervna kopija baterije: The internal battery is designed to maintain settings during power interruptions. No user maintenance is required for the battery.

Figure 6: Weather Resistance. This image highlights the timer's weather-resistant design, making it suitable for outdoor environments.

5. Otkrivanje problema

If you encounter issues with your myTouchSmart Digital Timer, refer to the following common problems and solutions:

6. Specifikacije

Detailed technical specifications for the myTouchSmart 33862 Digital Timer:

• Broj modela: 33862
• Boja: Black Dual Outlet - Sunsmart
• Materijal: Plastika
• Dimenzije proizvoda: 2"D x 3"Š x 6"V (5.08 cm D x 7.62 cm Š x 15.24 cm V)
• Težina artikla: 0.6 funti (9.6 unce / 272 grama)
• Broj postavki: 8 (custom programs)
• Električna ocjena: 125V~ 50/60Hz, 15A 1875W General Purpose/Resistive, 10A 1250W Tungsten, 1/2HP
• Kompatibilnost: LED, CFL, Incandescent, Halogen bulbs (including dimmable LED/CFL)
• Certifikati: CSA

Figure 7: Product Dimensions. This diagram provides precise measurements of the timer unit, including its height, width, depth, and cord length.

7. Informacije o garanciji

This myTouchSmart Digital Timer is covered by a 1 godine ograničene garancije from the date of purchase. This warranty covers defects in material and workmanship under normal use. For warranty claims or further details, please contact customer support.

8. Podrška

For additional assistance, technical support, or to inquire about replacement parts, please visit the official myTouchSmart website or contact their customer service department. Keep your product model number (33862) and purchase information readily available when seeking support.

Za detaljnije informacije možete pogledati i službeni korisnički priručnik u PDF formatu: myTouchSmart 33862 User Manual (PDF)
