Columbia CT010-330 Basecamp II Digitalni sat Uputstvo za upotrebu

Uvod

This manual provides detailed instructions for the Columbia CT010-330 Basecamp II Digital Display Quartz Multi-Color Watch. Designed for active individuals, this watch features a 100-hour chronograph with data storage, multiple interval timers, and alarms. It is also water-resistant up to 300 feet (91 meters).

Please read this manual thoroughly to understand the functions and proper operation of your watch.

Ključne karakteristike

• Digital Compass: For navigation and orientation.
• Thermometer: Measures ambient temperature.
• 24-Hour Countdown Timer: Useful for various activities.
• 50 Lap Memory: Records lap times for performance tracking.
• 10 Run Data Storage: Stores data for up to ten running sessions.
• 100-Hour Chronograph: Precise time measurement for extended periods.
• Five Interval Timers: Customizable timers for structured workouts.
• Three Alarms: For daily reminders and scheduling.
• Water Resistance: Up to 300 feet (91 meters).

Setup

Initial Power-On and Battery

Your Columbia CT010-330 watch comes with a product-specific battery pre-installed. If the display is blank or dim, the battery may need to be activated or replaced. Refer to the "Maintenance" section for battery information.

Podešavanje vremena i datuma

The watch features four buttons: LIGHT/SET (top left), MODE (bottom left), START/LAP/+ (top right), and STOP/SAVE/- (bottom right). Specific button functions may vary by mode.

1. From the Timekeeping mode, press and hold the SVJETLO/SET button until the display flashes, indicating setting mode.
2. Pritisnite MODE button to cycle through the settings: seconds, hours, minutes, year, month, day, 12/24-hour format.
3. Koristite START/LAP/+ dugme za povećanje trepćuće vrijednosti ili STOP/SAVE/- dugme za smanjenje.
4. Nakon što su sve postavke podešene, pritisnite dugme SVJETLO/SET button again to exit setting mode and save changes.

Uputstvo za upotrebu

Navigacija kroz načine rada

Pritisnite MODE button repeatedly to cycle through the various functions: Timekeeping, Chronograph, Timer, Alarm, Digital Compass, and Thermometer.

hronograf (štoperica)

The chronograph measures elapsed time up to 100 hours and includes 50 lap memory and 10 run data storage.

1. Uđite u hronografski režim pritiskom na MODE dugme.
2. Pritisnite START/LAP/+ za početak mjerenja vremena.
3. Pritisnite START/LAP/+ ponovo da biste zabilježili vrijeme kruga bez zaustavljanja glavnog mjerača vremena.
4. Pritisnite STOP/SAVE/- za pauziranje hronografa. Pritisnite START/LAP/+ nastaviti.
5. Dok ste pauzirali, pritisnite i držite STOP/SAVE/- za resetiranje hronografa na nulu.
6. To review stored lap times or run data, navigate to the data recall mode (usually accessible from chronograph mode by pressing a specific button, refer to on-screen prompts).

Interval Tajmeri

The watch features five independent interval timers for structured workouts.

1. Enter Timer mode using the MODE dugme.
2. Pritisnite i držite SVJETLO/SET da biste ušli u režim podešavanja tajmera.
3. Koristi MODE to select which of the five timers to set.
4. Koristi START/LAP/+ i STOP/SAVE/- to adjust the desired interval duration.
5. Pritisnite SVJETLO/SET za potvrdu i izlazak iz moda podešavanja.
6. Pritisnite START/LAP/+ to start the selected interval timer. An audible alert will sound when an interval completes.

Alarmi

Set up to three daily alarms.

1. Enter Alarm mode using the MODE dugme.
2. Pritisnite i držite SVJETLO/SET za ulazak u način podešavanja alarma.
3. Koristi MODE da biste odabrali Alarm 1, 2 ili 3.
4. Koristi START/LAP/+ i STOP/SAVE/- za podešavanje vremena alarma.
5. Pritisnite SVJETLO/SET za potvrdu i izlazak iz moda podešavanja.
6. U režimu alarma pritisnite START/LAP/+ da biste uključili/isključili odabrani alarm.

Digitalni kompas

The integrated digital compass provides directional readings.

1. Enter Compass mode using the MODE dugme.
2. Hold the watch level and away from strong magnetic fields (e.g., speakers, large metal objects).
3. The display will show the cardinal direction (N, S, E, W) and potentially a degree reading.
4. kalibracija: If readings appear inaccurate, the compass may need calibration. Refer to the watch's on-screen prompts or a more detailed manual if available for specific calibration steps. Typically, this involves rotating the watch in a figure-eight pattern.

Termometar

The watch can display the ambient temperature.

1. Enter Thermometer mode using the MODE dugme.
2. For accurate readings, remove the watch from your wrist for at least 20-30 minutes to allow it to acclimate to the ambient air temperature, as body heat can affect the sensor.
3. The temperature will be displayed in Celsius or Fahrenheit, depending on the unit setting (which can usually be changed in the general settings mode).

Pozadinsko osvetljenje

Pritisnite SVJETLO/SET button briefly to activate the backlight for improved visibility in low-light conditions.

Održavanje

Čišćenje sata

To maintain the appearance and functionality of your watch, regularly wipe the case and band with a soft, damp cloth. For the polyurethane band, mild soap and water can be used. Avoid harsh chemicals or abrasive materials.

Zamjena baterije

The watch requires 1 product-specific battery. When the display becomes dim or functions become erratic, it is likely time to replace the battery. Battery replacement should ideally be performed by a qualified watch technician to ensure proper sealing and maintain water resistance. Attempting to replace the battery yourself may void the warranty or compromise the watch's water resistance.

Otpornost na vodu

The Columbia CT010-330 is water-resistant up to 300 feet (91 meters). This means it is suitable for swimming, snorkeling, and recreational diving. Do not operate the buttons while the watch is submerged, as this can compromise the water seal. Avoid exposing the watch to extreme temperature changes, which can affect the seals.

Rješavanje problema

• Ekran je prazan ili taman: Baterija je možda slaba ili ispražnjena. Zamijenite bateriju kako je opisano u odjeljku Održavanje.
• Netačno vrijeme/datum: Ponovo podesite vrijeme i datum slijedeći upute u odjeljku Podešavanje. Provjerite je li ispravno odabran format 12/24 sata.
• Dugmad ne reagiraju: Ensure the watch is not in a locked mode (if applicable, though not specified for this model). If submerged, buttons should not be pressed. If the issue persists, a battery replacement or professional inspection may be required.
• Compass readings are inaccurate: Calibrate the digital compass. Ensure you are away from strong magnetic fields.
• Temperature readings are inconsistent: Remove the watch from your wrist for 20-30 minutes to allow it to acclimate to ambient temperature.

Specifikacije

Garancija i podrška

Informacije o garanciji

The warranty type for this product is "Contact seller of record." Please retain your proof of purchase. For specific warranty terms and conditions, contact the retailer or seller from whom you purchased the watch.

Korisnička podrška

For further assistance, technical support, or inquiries not covered in this manual, please contact Columbia customer service or the authorized retailer where the watch was purchased. You may find additional resources on the official Columbia website.
