1. Važne informacije o sigurnosti
Molimo vas da pažljivo pročitate sva uputstva prije upotrebe ovog uređaja. Sačuvajte ovaj priručnik za buduću upotrebu.
- Osigurajte da je aparat za led postavljen na stabilnu, ravnu površinu, dalje od direktne sunčeve svjetlosti i izvora toplote.
- Ne uranjajte uređaj, kabel za napajanje ili utikač u vodu ili druge tekućine.
- Isključite aparat za led iz električne utičnice prije čišćenja ili kada ga ne koristite.
- Nemojte koristiti uređaj s oštećenim kablom ili utikačem, ili nakon što uređaj pokvari ili je na bilo koji način oštećen.
- Koristite samo vodu za piće u aparatu za led.
- Držite djecu dalje od aparata za led tokom rada.
- Ovaj aparat je samo za upotrebu u domaćinstvu.
2. Proizvod je gotovview
The COSTWAY Countertop Ice Cube Maker is designed for convenient and efficient ice production. It features dual water filling methods, adjustable ice thickness, and a self-cleaning function.
Image: The COSTWAY Countertop Ice Cube Maker in a kitchen environment, demonstrating its use for chilling beverages.
Ključne karakteristike:
- Brza proizvodnja leda: Produces 16 clear square ice cubes in approximately 13 minutes, with a daily capacity of up to 34 lbs.
- Customizable Ice Thickness: Offers 13 adjustable thickness levels for ice cubes, from thin for fast chilling to thick for slow melting.
- Opcije dvostrukog punjenja vodom: Supports refilling via a 1.5L external tank or manual pouring into the internal tank.
- Smart Reservation System: A 24-hour timer function allows scheduling ice production.
- Samočišćenje bez napora: Built-in 20-minute deep clean function ensures hygiene.
- tihi rad: Operates at a noise level of ≤42dB.
Šta je u kutiji:
Image: Components included with the ice maker, illustrating the ice cube maker unit, ice basket, and ice scoop, along with product dimensions.
- 1 x Countertop Ice Maker
- 1 x korpa za led
- 1 x Lopatica za led
- 1 x Uputstvo za upotrebu (ovaj dokument)
3. Podešavanje
- Raspakivanje: Carefully remove all packaging materials. Inspect the ice maker for any damage.
- plasman: Place the ice maker on a flat, stable, and heat-resistant surface. Ensure there is adequate ventilation around the unit (at least 5 inches of space on all sides).
- Početno čišćenje: Before first use, clean the internal components. Refer to the 'Maintenance' section for detailed cleaning instructions.
- Priključak za napajanje: Uključite kabl za napajanje u uzemljenu električnu utičnicu.
- Punjenje vodom: The ice maker offers two ways to add water. It is recommended to use the external water tank for convenience.
Image: Illustration of the two water filling methods: using the external 1.5L removable tank or the internal tank.
- External Water Tank: Fill the 1.5L external water tank with potable water and place it securely on top of the ice maker.
- Internal Water Tank: Alternatively, open the lid and manually pour potable water into the internal reservoir up to the MAX fill line.
4. Operacija
- Uključeno: Pritisnite dugme za napajanje (1) to turn on the ice maker. The machine will begin the ice-making cycle.
- Podesite debljinu leda: The ice maker allows for 13 customized levels of ice thickness.
Image: Visual guide to adjustable ice thickness settings, showing thin, medium, and thick ice options and their corresponding ice-making times.
- Koristite '+'i'-' buttons to select your desired ice thickness.
- Thinner ice melts faster and is suitable for quick chilling.
- Thicker ice melts slower, ideal for preserving drinks like whiskey.
- Funkcija rezervacije 24 sata dnevno: This feature allows you to schedule ice production.
Image: Explanation of the 24-hour reservation function, detailing how to set the timer for automatic ice production.
- Pritisnite i držite dugme '-' button for more than 5 seconds to enter the timer settings.
- Adjust the desired start time using the '+'i'-' buttons.
- The machine will automatically start at the set time.
- Indikatori: The control panel features indicators for operational status.
Image: Close-up of the ice maker's control panel, highlighting the 'Add Water Reminder' and 'Ice Full Indicator' lights.
- Podsjetnik za dodavanje vode: An indicator light will illuminate when the water level is low, prompting you to refill.
- Indikator pune leda: An indicator light will illuminate when the ice basket is full, and the machine will pause ice production.
Image: The ice maker producing ice, highlighting its efficiency with details on production rate and basket capacity.
5. Održavanje
Funkcija samočišćenja:
The ice maker includes an automatic self-cleaning mode to maintain hygiene.
Image: Instructions for activating the self-cleaning function and the location of the bottom drain hole.
- Provjerite da li je aparat za led prazan, bez leda i vode.
- Napunite spremnik vode pitkom vodom.
- Long press the '+' button for 5 seconds to activate the self-cleaning mode.
- The machine will perform a 20-minute deep cleaning cycle.
- After the cycle, drain the water through the bottom drain hole.
Drenažna voda:
To drain water from the unit, locate the drain plug at the bottom of the ice maker. Place a container beneath it, remove the plug, and allow all water to drain. Replace the plug securely after draining.
Redovno čišćenje:
- Obrišite spoljašnjost mekom krpom, damp tkanina.
- Clean the ice basket and scoop with mild detergent and rinse thoroughly.
- For internal cleaning beyond the self-cleaning function, use a solution of water and vinegar, run a cycle, then drain and rinse with clean water.
6. Otkrivanje problema
Ako naiđete na probleme s vašim aparatom za led, pogledajte sljedeće uobičajene probleme i rješenja:
- Nema proizvodnje leda: Check if the power cord is securely plugged in. Ensure there is sufficient water in the tank. Verify that the ice basket is not full.
- Ice Cubes are Small or Cloudy: This may indicate low water temperature or a need for cleaning. Ensure the water is cold when added. Perform a self-cleaning cycle.
- "Add Water" Indicator On: Napunite rezervoar za vodu.
- "Ice Full" Indicator On: Uklonite led iz korpe.
- Neobična buka: Ensure the unit is on a level surface. Check for any obstructions in the ice-making mechanism.
Za probleme koji nisu ovdje obuhvaćeni, obratite se korisničkoj podršci.
7. Specifikacije
| Specifikacija | Detalj |
|---|---|
| Broj modela | 10747US-BK-CYSE |
| Ukupne dimenzije (Š x D x V) | 8.5" x 12" x 16" (22 x 30 x 41 cm) |
| Neto težina | 15.5 lbs (7 kg) |
| Voltage | 115V |
| Frekvencija | 60Hz |
| Current | 2.2A |
| Dnevna proizvodnja leda | 34 lbs (15 kg) |
| Kapacitet leda | 1.7 lbs (0.8 kg) |
| External Water Tank Capacity | 0.4 gal (1.5 l) |
| Operativni ciklus | 6-13 Mins (for 16 cubes) |
| Ice Type | Kocka |
| Nivo zvuka | ≤42dB |
| Radna temperatura | 50℉-109℉ (10℃-43℃) |
8. Garancija i podrška
This product comes with a standard manufacturer's warranty. For detailed warranty information, please refer to the warranty card included with your purchase or visit the official COSTWAY website.
If you require technical assistance, have questions about operation, or need to report a defect, please contact COSTWAY customer support. Have your model number (10747US-BK-CYSE) and purchase date ready when contacting support.
Kontakt informacije: Please refer to the contact details provided on the COSTWAY official webweb-mjesto ili vašu dokumentaciju o kupovini.
