1. Uvod
Thank you for choosing the GPEESTRAC BFNO-TD200-07 Bluetooth 5.4 Wireless Earbuds. These earbuds are designed to provide a high-quality audio experience with advanced features, including Bluetooth 5.4 connectivity, Hi-Fi sound, a multi-functional touch display on the charging case, and an ergonomic design for comfortable wear. This manual will guide you through the setup, operation, and maintenance of your new earbuds.
2. Sadržaj paketa
- GPEESTRAC BFNO-TD200-07 Wireless Earbuds (L/R)
- Charging Case with Touch Display
- USB kabel za punjenje tipa C
- Silikonske nastavke za uši (različite veličine)
- Uputstvo za upotrebu
3. Proizvod je gotovview
The GPEESTRAC BFNO-TD200-07 earbuds feature a compact design with a sophisticated charging case that includes a vibrant LED color touch panel. This panel allows for direct control over various functions without needing to access your smartphone. The earbuds are engineered for a secure and comfortable fit, making them suitable for extended use and active lifestyles.
The earbuds utilize advanced Bluetooth 5.4 technology for a stable and high-speed connection, minimizing audio interruptions and delays. They deliver balanced Hi-Fi sound with clear reproduction across all frequencies, supported by a 14mm flexible diaphragm for enhanced durability and sound quality.
4. Podešavanje
4.1 Početno uparivanje
- Uvjerite se da su slušalice potpuno napunjene.
- Otvorite poklopac kutijice za punjenje. Slušalice će automatski ući u način rada za uparivanje.
- Na pametnom telefonu ili uređaju s omogućenom Bluetooth vezom idite na postavke Bluetootha i potražite dostupne uređaje.
- Select "BFNO-TD200-07" from the list to connect.
- Nakon povezivanja, glasovna poruka će potvrditi uspješno uparivanje.
4.2 Automatsko ponovno povezivanje
After the initial pairing, the earbuds will automatically connect to the last paired device when you open the charging case lid, provided Bluetooth is enabled on your device and it is within range (up to 15 meters).
5. Uputstvo za upotrebu
5.1 Punjenje slušalica i kutijice
The charging case features a Type-C port for fast charging. The LED touch display on the case shows the precise battery level of both the case and individual earbuds, eliminating guesswork.
- Punjenje slušalica: Stavite slušalice u kutijicu za punjenje. Punjenje će se početi automatski.
- Punjenje kućišta: Connect the provided USB Type-C cable to the charging port on the case and a power source. The LED display will show the charging progress.
A full charge provides approximately 5 hours of playtime for the earbuds, and the charging case can recharge the earbuds 3-4 times, offering up to a week of use for typical commuting.
5.2 Touch Panel Functions
The charging case's LED color touch panel offers 12 distinct functions, providing convenient control without your smartphone.
Ključne funkcije uključuju:
- Muzički plejer: Control playback directly.
- Prebacivanje ANC načina rada: Toggle between Active Noise Cancellation (ANC) and Ambient Sound modes.
- Pronađite slušalice: Pronađite izgubljene slušalice.
- Funkcija tajmera: Postavite tajmer.
- Kontroler kamere: Koristite futrolu kao daljinski okidač za kameru vašeg telefona.
- Podešavanje jačine zvuka: Control audio volume.
- Odabir jezika: Promijenite jezik sistema.
- Glasovni asistent: Aktivirajte glasovnog asistenta na svom uređaju.
- Prikaz vremena: View trenutno vrijeme.
- Pozadina: Customize the display background.
- svjetiljka: Utilize a small flashlight function.
5.3 Sound Modes and Equalizer (EQ)
The earbuds offer various sound modes to enhance your listening experience.
- Aktivno poništavanje buke (ANC): Reduces ambient noise by up to -90dB, providing an immersive audio experience.
- Način ambijentalnog zvuka: Allows you to hear your surroundings while listening to audio, useful for safety.
- Poništavanje buke iz okoline (ENC): Enhances call clarity by reducing background noise during conversations.
The earbuds also support 5 EQ modes, allowing automatic customization of sound quality to match different music genres.
5.4 Upućivanje i primanje poziva
The earbuds are equipped with a microphone for hands-free calling. They support up to 4 hours of HD call time, ensuring clear conversations.
- Odgovori/Završi poziv: Jednom dodirnite senzor dodira na bilo kojoj slušalici.
- odbiti poziv: Pritisnite i držite senzor dodira na bilo kojoj slušalici 2 sekunde.
6. Održavanje
- čišćenje: Regularly clean the earbuds and charging case with a soft, dry cloth. Do not use abrasive cleaners or solvents.
- uši: Remove and clean the silicone eartips with mild soap and water, then dry thoroughly before reattaching.
- Skladištenje: Kada se ne koriste, slušalice čuvajte u kutijici za punjenje kako biste ih zaštitili od prašine i oštećenja.
- Izloženost vodi: While the earbuds are IPX7 waterproof, the charging case is not. Avoid exposing the charging case to water. Ensure earbuds are dry before placing them back in the case.
7. Otkrivanje problema
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Slušalice se ne uparuju | Slušalice nisu u načinu rada za uparivanje; Bluetooth isključen na uređaju; prethodno upareni uređaj ometa rad. | Ensure earbuds are in pairing mode (open case lid). Turn on Bluetooth on your device. Forget previous connections on your device and try pairing again. |
| Nema zvuka iz slušalica | Volume too low; earbuds not connected; media not playing. | Increase volume on both earbuds and connected device. Check Bluetooth connection. Ensure media is playing on your device. |
| Problemi s punjenjem | Charging cable faulty; charging port dirty; earbuds not seated correctly. | Try a different Type-C cable and power adapter. Clean the charging contacts on earbuds and case. Ensure earbuds are properly seated in the case. |
| Povremeni prekidi veze/zvuka | Udaljenost od uređaja; smetnje; slaba baterija. | Keep earbuds within 15 meters of your device. Avoid strong electromagnetic interference. Charge earbuds and case fully. |
| Unwanted voice prompts in foreign language | Language setting incorrect. | Use the language selection function on the charging case's touch panel to change to English. |
8. Specifikacije
| Feature | Specifikacija |
|---|---|
| Broj modela | BFNO-TD200-07 |
| Brand | GPEESTRAC |
| Bluetooth verzija | 5.4 + EDR |
| Vrijeme reprodukcije slušalica | Pribl. 5-6 sati |
| Ukupno vrijeme reprodukcije (s kućištem za punjenje) | Approx. 32 hours (up to 200 hours standby) |
| Port za punjenje | USB Type-C |
| Otpornost na vodu | IPX7 (samo slušalice) |
| Driver Size | 14mm |
| Communication Range | Do 15 metara |
| GTIN/UPC | 607602427503 |
9. Sigurnosne informacije
- Nemojte rastavljati ili modificirati proizvod.
- Keep away from extreme temperatures, humidity, and corrosive substances.
- Izbjegavajte produženo izlaganje visokim nivoima glasnoće kako biste spriječili oštećenje sluha.
- Čuvati van domašaja djece i kućnih ljubimaca.
- Odložite proizvod odgovorno u skladu sa lokalnim propisima.
10. Garancija i podrška
Specific warranty details and customer support contact information are not provided in the product data. Please refer to the product packaging or the retailer's webstranica za reklamacije u vezi s garancijom i upite za podršku.
