1. Uvod i krajview
Thank you for choosing the INNOVATE® LED Floor Lamp. This manual provides detailed instructions for the assembly, operation, and maintenance of your new dimmable RGB corner lamp. Designed for modern living spaces, this lamp offers versatile lighting options to enhance your home, gaming setup, or party atmosphere.
The INNOVATE® LED Floor Lamp features a sleek, minimalist design, standing at 1.4 meters tall, and is equipped with a remote control for easy adjustment of brightness, speed, and a wide spectrum of colors and lighting modes. Its robust aluminum construction ensures durability, while the energy-efficient LED technology provides long-lasting illumination.
Image: The INNOVATE® LED Floor Lamp illuminating a room with vibrant colors, controlled by a remote.
2. Sigurnosna uputstva
- Prije montaže i upotrebe pažljivo pročitajte sva uputstva.
- Zadrži lamp away from water and moisture. This product is rated IP20, meaning it is protected against solid objects over 12.5mm but has no protection against water.
- Ne pokušavajte rastaviti ili modificirati lampSva servisiranja prepustite kvalifikovanom osoblju.
- Osigurajte napajanje voltage odgovara lamp's requirements (230 Volts).
- Isključite lamp iz utičnice prije čišćenja ili bilo kakvog održavanja.
- Daljinski upravljač i baterije držite van dohvata djece.
3. Sadržaj paketa
Molimo Vas da provjerite pakovanje kako biste bili sigurni da su sve komponente prisutne:
- LED Lamp Bar
- Lamp Base (Stand)
- Kabel za napajanje s utikačem
- Remote Control (Batteries not included; requires 2x AAA batteries)
- Foot Switch (integrated into power cable)
- Korisnički priručnik (ovaj dokument)
Slika: Vizualni prikaz lamp's dimensions (1400mm height, 350mm base) and included accessories: remote control, foot switch, and power adapter.
4. Značajke proizvoda
- RGB Color Spectrum: Offers over 3,000,000 color combinations for dynamic lighting.
- Zatamnjenje: Adjust brightness levels to suit any mood or activity.
- daljinski upravljač: Conveniently control colors, brightness, speed, and various lighting modes from a distance.
- Nožni prekidač: An additional on/off control located on the power cable for quick access.
- moderan dizajn: Sleek, black aluminum body with a right-angled design, perfect for corner placement.
- Energetski efikasan: 22W LED lamp with 1760 lumens output and an energy efficiency of 80 lumen/W.
- Dug životni vek: Predviđen za preko 50,000 sati rada.
- Jednostavna instalacija: Simple plug-and-play assembly.
Image: A collage demonstrating the lamp's capability to display over 3,000,000 color combinations, including red, green, blue, white, and various dynamic modes.
Image: An infographic summarizing the lamp's advantages: Plug & Play, Dimmable, Color Change, Ultra-flat Design, over 3 million colors, and a lifespan exceeding 50,000 hours. It also notes the product is 'Designed in Austria'.
5. Postavljanje i montaža
The INNOVATE® LED Floor Lamp is designed for quick and easy assembly. Follow these steps:
- Step 1: Attach the Base. Pažljivo poravnajte lamp bar with the base and secure it. Ensure the connection is firm.
- Step 2: Connect the Cables. Locate the plug-and-play connectors on the lamp bar and the base. Connect them securely.
- Step 3: Position the Lamp. Stavite sklopljeni lamp in your desired location, ideally in a corner to maximize its ambient lighting effect.
- Korak 4: Uključite. Spojite kabel za napajanje na lamp and then plug it into a standard 230V electrical outlet.
Image: A four-panel diagram illustrating the assembly process: 1. Connecting the lamp bar to the base, 2. Securing the connection, 3. Connecting the power cable, and 4. The fully assembled lamp.
6. Uputstvo za upotrebu
Your INNOVATE® LED Floor Lamp can be operated using the included remote control or the integrated foot switch.
6.1. Korištenje daljinskog upravljača
Before first use, insert 2x AAA batteries into the remote control (not included). The remote allows for comprehensive control:
- Dugme za napajanje: Okreće lamp On/Off.
- Točak u boji: Select any static color by touching the color wheel.
- Dugmad za osvjetljenje: Povećajte ili smanjite intenzitet svjetla.
- Dugmad za način rada: Cycle through various dynamic lighting effects (e.g., fade, jump, flash).
- Dugmad za brzinu: Adjust the speed of dynamic lighting modes.
- DIY Buttons: Some remotes may have customizable buttons to save your favorite settings.
Image: The INNOVATE LED Floor Lamp emitting a vibrant spectrum of colors, with its remote control prominently displayed, symbolizing ease of use.
6.2. Using the Foot Switch
The foot switch, located on the power cable, provides a simple on/off function. Press once to turn the lamp on, press again to turn it off. This switch does not control colors or modes.
7. Održavanje
To ensure the longevity and optimal performance of your INNOVATE® LED Floor Lamp, slijedite ove jednostavne smjernice za održavanje:
- čišćenje: Isključite lamp from the power supply before cleaning. Use a soft, dry cloth to wipe down the lamp bar and base. Do not use abrasive cleaners or solvents.
- Otprašivanje: Redovno brišite prašinu sa lamp kako bi se spriječilo nakupljanje, koje može utjecati na svjetlosni tok i estetiku.
- Baterije za daljinski upravljač: Replace the AAA batteries in the remote control when its responsiveness decreases.
- Skladištenje: Ako pohranjujete lamp for an extended period, disconnect it from power and store it in a cool, dry place.
8. Otkrivanje problema
If you encounter any issues with your INNOVATE® LED Floor Lamp, molimo pogledajte sljedeće uobičajene korake za rješavanje problema:
| Problem | Mogući uzrok | Rješenje |
|---|---|---|
| Lamp se ne uključuje. | Nema napajanja; labava veza; neispravna utičnica. | Provjerite je li kabel za napajanje sigurno priključen u utičnicuamp i zidnu utičnicu. Testirajte utičnicu s drugim uređajem. |
| Daljinski upravljač ne radi. | Prazne baterije; daljinski upravljač izvan dometa; prepreka. | Replace the batteries in the remote control. Ensure you are within range and there are no obstructions between the remote and the lampprijemnik. |
| Colors are not changing or lamp is stuck on one color. | Remote control issue; temporary software glitch. | Try replacing remote batteries. Unplug the lamp from the power outlet for 30 seconds, then plug it back in to reset. |
| Lamp treperi. | Nestabilno napajanje; labava veza. | Ensure the power connection is stable. Try plugging into a different outlet. |
Ako problem i dalje postoji nakon što ste isprobali ove korake, obratite se korisničkoj podršci.
9. Specifikacije
| Atribut | Specifikacija |
|---|---|
| Brand | INNOVATE® |
| Broj modela | 38364 |
| Dimenzije proizvoda | 1.79 x 35 x 140 cm (0.7 x 13.8 x 55.1 inča) |
| Težina | 732 g (1.61 lbs) |
| Materijal | Aluminij (tijelo), Plastika (dampshade), Stainless Steel (base) |
| Boja | Crna |
| Tip završetka | Mat |
| Vrsta izvora svjetlosti | LED |
| Wattage | 22 Watts |
| Voltage | 230 Volts |
| Luminous Flux | 1760 lumena |
| Energetska efikasnost | 80 lumena/W |
| Indeks prikazivanja boja (CRI) | > 80 |
| Ugao snopa | 120 stepeni |
| Životni vijek | Rated 25,000 hours (advertised >50,000 hours) |
| IP Rating | IP20 |
| Izvor napajanja | Corded Electric |
| Stil prekidača | Push Button (Foot Switch) |
| Posebne karakteristike | Dimmable, RGB Color Changing, Remote Control |
| Baterije su potrebne | Yes (for remote control, not included) |
Image: A comprehensive product data sheet providing detailed technical specifications and performance metrics for the lamp.
Image: The EU Energy Label for the INNOVATE LED Floor Lamp, Model 38364, indicating its energy efficiency class G and energy consumption of 22 kWh/1000h. For more details, visit the official EPREL database: https://eprel.ec.europa.eu/qr/909813
10. Garancija i podrška
INNOVATE® is committed to providing high-quality products and excellent customer service. While specific warranty details are not provided in this manual, our German customer support team is available to assist you with any questions, concerns, or issues you may encounter with your LED Floor Lamp.
For support, please refer to the contact information provided on your purchase receipt or the INNOVATE® official website.
Image: A visual representing the INNOVATE team, emphasizing their long-standing experience in LED products and commitment to quality, innovation, and customer support.
