Clarathon HCD-55 Spa Ozonator Kit Instruction Manual

1. Uvod

The Clarathon HCD-55 Spa Ozonator Kit is designed to provide ozone generation for hot tubs, swim spas, and cold plunge tanks up to 2500 gallons. This kit features dual ozone setpoints (50mg/Hr and 200mg/Hr) to accommodate various water volumes and is compatible with universal 120V/240V electrical systems. This manual provides essential information for the safe and effective installation, operation, and maintenance of your ozonator.

Image 1.1: Clarathon HCD-55 Spa Ozonator Kit, including the ozonator unit, tubing, clamps, and check valve.

2. Sigurnosne informacije

Please read all safety instructions before installing or operating this device. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• električna sigurnost: Always disconnect power to the spa or hot tub before performing any installation or maintenance. This unit operates on 120V or 240V; ensure proper wiring by a qualified electrician if you are unsure.
• Ozone Exposure: Ozone (O₃) is a powerful oxidizer. While beneficial for water sanitation, direct inhalation of high concentrations of ozone can be harmful. Ensure proper ventilation and installation to prevent ozone gas from accumulating in enclosed spaces.
• Prijedlog 65 Upozorenje: Ovaj proizvod može sadržavati kemikalije za koje je u državi Kalifornija poznato da uzrokuju rak i urođene mane ili druge reproduktivne štete. Operite ruke nakon rukovanja.
• Kontakt s vodom: Prevent water from entering the ozonator unit. The check valve is crucial for preventing water backflow into the generator.
• Djeca i kućni ljubimci: Keep the ozonator and its components out of reach of children and pets.

3. Sadržaj paketa

Prije nego što nastavite s instalacijom, provjerite jesu li sve komponente prisutne i neoštećene:

• Clarathon HCD-55 Ozone Generator Unit
• 6 feet of Ozone Tubing (1/4 inch)
• Kontrolni ventil
• Crijevo Clamps (količina 4)
• Veze
• 6 ft. Power Cord with AMP-4 Connector

Image 3.1: All components included in the Clarathon HCD-55 Spa Ozonator Kit.

4. Postavljanje i instalacija

Installation of the Clarathon HCD-55 Ozonator is considered moderate difficulty. If you are not comfortable with electrical or plumbing work, consult a qualified professional.

4.1 Koraci prije instalacije

1. Isključite napajanje: Turn off all power to your hot tub or spa at the circuit breaker.
2. Locirajte područje instalacije: Choose a dry, protected location for the ozonator unit, away from direct water spray and excessive heat. Ensure there is enough space for mounting and tubing connections.
3. Identify Ozone Injector: Locate your spa's existing ozone injector (venturi) in the plumbing system. This is where the ozone tubing will connect.

4.2 Mounting the Ozonator

• Mount the ozonator unit vertically, if possible, to allow for proper drainage and air circulation.
• Use appropriate fasteners (not included) to secure the unit to a stable surface.

4.3 Tubing and Check Valve Connection

1. Connect one end of the 1/4" ozone tubing to the ozone output barb on the ozonator unit. Secure with a hose clamp.
2. Install the check valve into the ozone tubing. The arrow on the check valve must point towards the spa's ozone injector, ensuring ozone flows into the water and preventing water from flowing back into the ozonator. Secure both ends of the check valve with hose clamps.
3. Connect the other end of the ozone tubing to your spa's ozone injector barb. Secure with a hose clamp.
4. Create a small loop in the ozone tubing above the water line to act as a water trap, further preventing water from reaching the ozonator.

Image 4.1: Installation diagram for the Clarathon HCD-55 Ozonator.

4.4 Električni priključak

• The HCD-55 features universal voltage (120V/240V) autosensing.
• Connect the provided 6 ft. power cord with the AMP-4 connector to the corresponding receptacle on your spa's control pack. Ensure the connector is fully seated.

Image 4.2: Detail of the AMP-4 electrical connector.

Image 4.3: Installation difficulty for the ozonator is rated as moderate.

4.5 Nakon instalacije

• Once installation is complete, restore power to the spa.
• Check for any leaks in the plumbing connections.
• Verify that the ozonator is operating. A faint ozone smell near the spa's water surface or a small indicator light on the unit (if present) may confirm operation.

5. Uputstvo za upotrebu

The Clarathon HCD-55 Ozonator operates automatically when power is supplied through the spa's control system. It is designed to work in conjunction with your spa's filtration cycles.

• Automatski rad: The ozonator will activate and generate ozone during the spa's programmed filtration cycles. No manual intervention is typically required for daily operation.
• Dual Setpoints: The HCD-55 offers dual ozone output setpoints (50mg/Hr and 200mg/Hr). The unit automatically adjusts its output based on the spa's requirements or may be pre-set to one of these levels. Consult your spa's manual or Clarathon support for specific details on setpoint selection if applicable to your model.
• Proizvodnja ozona: Ozone is produced by an internal corona discharge cell. This ozone is then injected into the spa water via the venturi system, assisting in water sanitation.

Image 5.1: Visual representations of ozone technology and the ozone molecule.

6. Održavanje

Regular maintenance ensures optimal performance and longevity of your ozonator.

• Interval zamjene: The Clarathon HCD-55 Ozonator has a recommended replacement interval of 30 mjeseca. Ozone generators gradually lose efficiency over time. Replacing the unit at this interval ensures continuous effective sanitation.
• Zabilježite datum instalacije: It is recommended to write down the installation date on the label provided on the ozonator unit for easy tracking of its lifespan.

Image 6.1: Ozonator label for recording installation date and noting the 30-month replacement interval.

• Check Tubing and Check Valve: Periodically inspect the ozone tubing for kinks, cracks, or blockages. Ensure the check valve is functioning correctly and preventing water backflow. Replace if any damage is observed.
• Držite uređaj suhim: Ensure the ozonator unit remains dry and free from moisture.

Image 6.2: Ozone works in conjunction with other sanitizers like bromine.

7. Otkrivanje problema

If your Clarathon HCD-55 Ozonator is not performing as expected, consider the following:

• No Ozone Smell/Output:
  • Verify power is supplied to the spa and the ozonator's power cord is securely connected.
  • Check if the spa's filtration cycle is active, as the ozonator typically operates during these times.
  • Inspect the ozone tubing for kinks, blockages, or damage.
  • Ensure the check valve is installed correctly and not blocked.
  • If the unit is older than 30 months, its ozone production may have significantly decreased, requiring replacement.
• Water in Ozone Tubing/Ozonator:
  • Immediately disconnect power to the ozonator and spa.
  • Inspect the check valve for proper installation and function. Replace if faulty.
  • Ensure the tubing loop (water trap) is correctly positioned above the water line.
• Jedinica se ne uključuje:
  • Check the electrical connection at the spa pack.
  • Confirm the spa's control system is providing power to the ozonator outlet.

For persistent issues, contact Clarathon customer support.

8. Specifikacije

9. Garancija

The Clarathon HCD-55 Spa Ozonator Kit is backed by a 2 godine garancije od datuma kupovine. Ova garancija pokriva nedostatke u materijalu i izradi pri normalnoj upotrebi i servisiranju. Molimo sačuvajte dokaz o kupovini za reklamacije.

Image 9.1: Clarathon 2-Year Warranty.

The warranty does not cover damage resulting from improper installation, misuse, neglect, accident, or unauthorized repairs or modifications. The recommended replacement interval of 30 months is a guideline for optimal performance, not a warranty period extension.

10. Podrška

For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Clarathon customer support. Refer to the Clarathon webAktuelne kontakt informacije potražite na web stranici ili u dokumentaciji o kupovini.

When contacting support, please have your product model (HCD-55) and serial number available. The serial number can be found on the label on the ozonator unit (refer to Image 6.1).
