CLEANmaxx Pro Power Cordless Cyclone Vacuum Cleaner

Važna sigurnosna uputstva

Please read this instruction manual carefully before using the appliance and keep it for future reference. Always observe all safety instructions.

• This appliance is designed for vacuuming normal household dust. Do not use it to vacuum liquids, wet substances (e.g., wet carpet shampoo), burning ashes, cigarette butts, matches, flammable or combustible substances, very fine dust (e.g., concrete dust), ashes, toners, or sharp, hard objects like glass shards.
• Držite uređaj podalje od djece i kućnih ljubimaca.
• Koristite samo originalni pribor i rezervne dijelove.
• Do not operate the appliance if it is damaged or if the power cord/adapter is faulty.
• Prije upotrebe provjerite jesu li spremnik za prašinu i filteri ispravno postavljeni.
• Ne blokirajte otvore za ventilaciju tokom rada.

Sadržaj paketa

Image: All components of the CLEANmaxx Pro Power Cordless Cyclone Vacuum Cleaner, including the main unit, extension tube, various nozzles, battery, and wall mount.

Molimo Vas da provjerite da li se u paketu nalaze svi artikli:

• Cordless Cyclone Vacuum Cleaner (main unit)
• Extension Tube (metal)
• Power Rotation Electric Brush
• Pukotina mlaznica
• Brush Nozzle
• Suction Tube Holder for Crevice Brush and Brush
• Li-ion Battery (removable)
• AC adapter
• Wall Mount with Fixing Material

Sastavljanje i početno podešavanje

Attaching the Extension Tube and Power Brush

Image: The CLEANmaxx vacuum cleaner fully assembled with the extension tube and power brush attached, ready for use.

1. Insert the metal extension tube into the main vacuum unit until it clicks into place.
2. Attach the Power Rotation Electric Brush to the other end of the extension tube, ensuring it is securely fastened.
3. For handheld use, attach the desired nozzle (crevice or brush) directly to the main unit.

Punjenje baterije

Before first use, fully charge the Li-ion battery. The battery is removable for convenient charging.

1. Connect the AC adapter to the charging port on the battery or the main unit if the battery is inserted.
2. Uključite AC adapter u utičnicu.
3. LED indikator će prikazivati ​​status punjenja. Potpuno punjenje traje otprilike 5 sat.

Montaža na zid

The included wall mount allows for convenient storage of your vacuum cleaner and accessories.

1. Choose a suitable location near a power outlet for easy charging.
2. Use the provided fixing material (screws and wall plugs) to securely mount the bracket to the wall.
3. The suction tube holder can be attached to the extension tube for storing the crevice and brush nozzles.

Image: The suction tube holder attached to the extension tube, providing a convenient storage spot for the smaller nozzles.

Operacija

Uključivanje/isključivanje

Press the power button once to turn the vacuum cleaner on. Press it again to turn it off. The vacuum cleaner features two suction levels for different cleaning needs.

Korištenje različitih priloga

The CLEANmaxx vacuum cleaner is versatile and can be adapted for various cleaning tasks.

• Power Rotation Electric Brush: Ideal for carpets and hard floors. The rotating brush effectively picks up dust and debris.


Slika: Detaljna view of the Power Rotation Electric Brush head, showing the internal rotating brush mechanism.

• Mlaznica za pukotine: Perfect for narrow gaps, corners, and hard-to-reach areas like between sofa cushions or car seats.
• Mlaznica za četkicu: Suitable for delicate surfaces, upholstery, keyboards, and furniture. The soft bristles help to loosen dust without scratching.


Image: A user demonstrating the handheld use of the vacuum cleaner with the brush attachment to clean a sofa.

• Ručni način rada: Detach the extension tube to use the main unit as a compact handheld vacuum for quick clean-ups, car interiors, or stairs.

Image: The CLEANmaxx vacuum cleaner in handheld mode, being used to efficiently clean a set of stairs.

Njega i održavanje

Redovno održavanje osigurava optimalne performanse i produžava vijek trajanja vašeg usisivača.

Pražnjenje kante za otpatke

The bagless cyclonic technology features an easy-to-empty dust container.

1. Pronađite dugme za otpuštanje posude za prašinu na glavnoj jedinici.
2. Pritisnite dugme da biste odvojili posudu za prašinu.
3. Držite kantu za smeće iznad kante za smeće i otvorite donji poklopac da biste ispraznili sadržaj.
4. Zatvorite poklopac i ponovo pričvrstite posudu za prašinu na glavnu jedinicu dok ne klikne sigurno.

Čišćenje filtera

The vacuum cleaner uses a two-chamber filtration system with a stainless steel filter and a foam filter. Clean them regularly to maintain suction power.

1. Uklonite kantu za prašinu kao što je gore opisano.
2. Carefully remove the stainless steel filter and the foam filter from the dustbin.
3. Tap the filters gently to remove loose dust. For a more thorough cleaning, rinse them under running water.
4. Ensure the filters are completely dry before reinserting them into the dustbin and reattaching the dustbin to the vacuum cleaner. Do not use the vacuum cleaner with wet filters.

Cleaning the Power Rotation Brush

Periodically check the Power Rotation Electric Brush for tangled hair or debris.

1. Turn off the vacuum cleaner and detach the Power Rotation Electric Brush.
2. Use scissors or a brush to remove any hair, threads, or debris wrapped around the brush roller.
3. Ensure the brush roller spins freely before reattaching the brush head.

Rješavanje problema

If you encounter any issues with your CLEANmaxx vacuum cleaner, refer to the table below for common problems and solutions.

Tehničke specifikacije

Garancija i korisnička podrška

Specific warranty information for the CLEANmaxx Pro Power Cordless Cyclone Vacuum Cleaner is not provided in this manual. For details regarding warranty coverage, claims, or technical support, please refer to the product packaging, the retailer from whom you purchased the product, or contact the manufacturer directly.

Manufacturer: ds Produkte GmbH
