Faber 110.0439.951 Uputstvo za upotrebu kuhinjske nape

1. Proizvod je gotovview

The Faber 110.0439.951 is a high-performance cooker hood designed for integration into kitchen cabinets. It features an electronic sensor control, an auto-start function, and an EVO diffuser for efficient air extraction. The unit is equipped with bright LED lighting and constructed from durable stainless steel, ensuring both functionality and a sleek aesthetic in your kitchen.

Slika 1.1: Prednja strana view of the Faber 110.0439.951 Cooker Hood, showcasing its stainless steel finish and integrated LED lights.

2. Postavljanje i instalacija

Proper installation is crucial for the optimal performance and safety of your cooker hood. This model is designed for built-in mounting within a kitchen cabinet.

2.1 Important Dimensions and Clearances

• Dimenzije proizvoda: 32 cm (depth) x 90 cm (width) x 33.9 cm (height).
• Težina: Otprilike 9.2 kg.
• Prečnik izlaza vazduha: Ø 150/120 mm.
• Minimum Distance from Hob: The minimum distance between the lowest part of the hood and the highest point of the hob should be 53 cm. This clearance is essential for safety and efficient extraction.

Figure 2.1: Technical drawing illustrating the dimensions and recommended clearances for installation. Note the air outlet diameter and overall unit size.

Figure 2.2: The Faber cooker hood seamlessly integrated into a kitchen cabinet, demonstrating its built-in mounting type.

3. Uputstvo za upotrebu

The Faber 110.0439.951 cooker hood is equipped with user-friendly electronic sensor controls for easy operation.

3.1 Kontrolna tabla

The electronic sensor control panel is located on the front of the hood. It allows you to adjust fan speed and lighting.

3.2 Postavke brzine ventilatora

The hood offers three standard fan speeds and an additional intensive operating mode for powerful extraction when needed.

• Brzina 1 (niska): Ideal for light cooking or maintaining air quality.
• Brzina 2 (Srednja): Pogodno za opšte kulinarske zadatke.
• Brzina 3 (Visoka): For heavier cooking or when more extraction is required.
• Intenzivni način rada: Provides maximum extraction power for a limited time to quickly clear strong odors or smoke. The hood will automatically revert to a lower speed after a set period.

3.3 Rasveta

The hood is fitted with two energy-efficient LED lights, providing ample illumination for your cooking area. Use the dedicated button on the control panel to switch the lights on or off.

4. Održavanje i čišćenje

Regular maintenance ensures the longevity and efficient operation of your Faber cooker hood.

4.1 Čišćenje filtera za masnoću

The cooker hood is equipped with a cassette-type grease filter, which is washable in a dishwasher. It is recommended to clean the grease filter regularly, depending on your cooking habits, to maintain optimal air extraction performance.

1. Carefully remove the grease filter from the hood. Refer to the installation diagram for filter location.
2. Place the filter in your dishwasher. Use a standard dishwasher detergent.
3. Run a normal wash cycle.
4. Allow the filter to dry completely before re-installing it into the hood.

Napomena: The filter may discolor slightly after dishwasher cleaning, but this does not affect its performance.

4.2 Vanjsko čišćenje

Clean the stainless steel exterior of the hood with a soft cloth and a mild, non-abrasive cleaning agent. Avoid using harsh chemicals or abrasive pads, as these can damage the finish.

5. Otkrivanje problema

This section provides solutions to common issues you might encounter with your cooker hood. If the problem persists, please contact customer support.

• Napa se ne uključuje:
  • Provjerite je li kabel za napajanje sigurno uključen u ispravnu utičnicu.
  • Provjerite da li je prekidač strujnog kruga isključen.
• Loše performanse ekstrakcije:
  • Ensure the grease filters are clean and not clogged.
  • Check for any obstructions in the ducting system.
  • Verify that the fan speed is set appropriately for the cooking task.
• Neobična buka:
  • Check if the grease filters are correctly installed.
  • Ensure there are no loose parts or foreign objects in the fan area.
• Svjetla ne rade:
  • Check if the LED lights need replacement. Consult the specifications for bulb type.

6. Tehničke specifikacije

Detailed technical specifications for the Faber 110.0439.951 Cooker Hood.

Figure 6.1: The energy efficiency label for the Faber 110.0439.951 cooker hood, indicating its 'A' energy class rating and other performance metrics.

7. Garancija i podrška

For warranty information, technical support, or service inquiries, please contact Faber customer service using the details below.

• Proizvođač: Faber S.p.A.
• Customer Service Name: Faber_Customer_Service_
• Email: hs-eprel-info.eu@faberspa.com
• Webstranica: www.faberspa.com
• Telefon: +39 0732 691691
• Adresa: Viale XIII Luglio 160, 60044 Fabriano (An), Italija
• EPREL registarski broj: 1310531 (View on EPREL Database)
